Icom IC-PW1 Service Manual

5 - 2
S.=Surface mount
L36 6200003260 S.COIL NL 322522T-101J
L37 6180000990 COIL LAL 04NA 101K
L38 6200003950 S.COIL HF50ACC 322513-T
L39 6200003950 S.COIL HF50ACC 322513-T
L40 6200003950 S.COIL HF50ACC 322513-T
L41 6200003950 S.COIL HF50ACC 322513-T
L42 6200003950 S.COIL HF50ACC 322513-T
L43 6200003950 S.COIL HF50ACC 322513-T
L44 6200003950 S.COIL HF50ACC 322513-T
L45 6200003950 S.COIL HF50ACC 322513-T
L46 6200003950 S.COIL HF50ACC 322513-T
L47 6200003950 S.COIL HF50ACC 322513-T
L48 6200003950 S.COIL HF50ACC 322513-T
L49 6200003260 S.COIL NL 322522T-101J
L50 6200003950 S.COIL HF50ACC 322513-T
L51 6200003260 S.COIL NL 322522T-101J
L52 6200003260 S.COIL NL 322522T-101J
L54 6200003950 S.COIL HF50ACC 322513-T
L55 6200003950 S.COIL HF50ACC 322513-T
L56 6200003950 S.COIL HF50ACC 322513-T
L57 6200003950 S.COIL HF50ACC 322513-T
L58 6200003950 S.COIL HF50ACC 322513-T
L59 6200003950 S.COIL HF50ACC 322513-T
L60 6200003950 S.COIL HF50ACC 322513-T
L61 6200003950 S.COIL HF50ACC 322513-T
L62 6200003950 S.COIL HF50ACC 322513-T
L63 6200003950 S.COIL HF50ACC 322513-T
L64 6200003950 S.COIL HF50ACC 322513-T
L65 6200003950 S.COIL HF50ACC 322513-T
L66 6200003950 S.COIL HF50ACC 322513-T
L67 6200003950 S.COIL HF50ACC 322513-T
L68 6200003950 S.COIL HF50ACC 322513-T
L69 6200003950 S.COIL HF50ACC 322513-T
L70 6200003950 S.COIL HF50ACC 322513-T
L71 6200003950 S.COIL HF50ACC 322513-T
L72 6200003950 S.COIL HF50ACC 322513-T
L73 6200003950 S.COIL HF50ACC 322513-T
L74 6200003950 S.COIL HF50ACC 322513-T
L75 6200003260 S.COIL NL 322522T-101J
L76 6200003260 S.COIL NL 322522T-101J
L77 6200001830 S.COIL NL 322522T-100J
L78 6200001830 S.COIL NL 322522T-100J
L79 6200001830 S.COIL NL 322522T-100J
L80 6910003570 COIL 2943-666663
L81 6200003260 S.COIL NL 322522T-101J
L82 6200003260 S.COIL NL 322522T-101J
L100 6200003260 S.COIL NL 322522T-101J
L101 6200003260 S.COIL NL 322522T-101J
L104 6200003950 S.COIL HF50ACC 322513-T
L105 6200003950 S.COIL HF50ACC 322513-T
L106 6200003950 S.COIL HF50ACC 322513-T
L107 6910003570 COIL 2943-666663
L108 6910003570 COIL 2943-666663
L109 6200003260 S.COIL NL 322522T-101J
L110 6200003260 S.COIL NL 322522T-101J
L111 6200003950 S.COIL HF50ACC 322513-T
L113 6200003260 S.COIL NL 322522T-101J
L114 6180000900 COIL LAL 03NA 101K
L115 6180000880 COIL LAL 03NA 100K
L116 6180000880 COIL LAL 03NA 100K
L117 6200003260 S.COIL NL 322522T-101J
L118 6200003260 S.COIL NL 322522T-101J
L119 6200003260 S.COIL NL 322522T-101J
L120 6200003260 S.COIL NL 322522T-101J
L121 6200003950 S.COIL HF50ACC 322513-T
L122 6200003950 S.COIL HF50ACC 322513-T
L123 6200003260 S.COIL NL 322522T-101J
L124 6200003260 S.COIL NL 322522T-101J
R1 7030003840 S.RESISTOR ERJ3GEYJ 225 V (2.2 MΩ)
R2 7030003740 S.RESISTOR ERJ3GEYJ 334 V (330 kΩ)
R3 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R4 7310002580 S.TRIMMER RV-108 (RH03A3A15X05A) 104
R5 7310002840 S.TRIMMER RV-160 (RH03A3A16) 105
R6 7310002580 S.TRIMMER RV-108 (RH03A3A15X05A) 104
R7 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
R9 7030003840 S.RESISTOR ERJ3GEYJ 225 V (2.2 MΩ)
R10 7030003750 S.RESISTOR ERJ3GEYJ 394 V (390 kΩ)
R11 7030003810 S.RESISTOR ERJ3GEYJ 125 V (1.2 MΩ)
R12 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R13 7030003810 S.RESISTOR ERJ3GEYJ 125 V (1.2 MΩ)
REF ORDER
DESCRIPTION
NO. NO.
[MAIN UNIT]
R14 7030003690 S.RESISTOR ERJ3GEYJ 124 V (120 kΩ)
R15 7310002740 S.TRIMMER RV-150 (RH03A3A14X0FC) 103
R22 7310002580 S.TRIMMER RV-108 (RH03A3A15X05A) 104
R23 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R24 7030003750 S.RESISTOR ERJ3GEYJ 394 V (390 kΩ)
R25 7030003750 S.RESISTOR ERJ3GEYJ 394 V (390 kΩ)
R26 7310002820 S.TRIMMER RV-158 (RH03A3AS5) 474
R27 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R28 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R29 7030003750 S.RESISTOR ERJ3GEYJ 394 V (390 kΩ)
R30 7030003750 S.RESISTOR ERJ3GEYJ 394 V (390 kΩ)
R31 7310002820 S.TRIMMER RV-158 (RH03A3AS5) 474
R32 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R33 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R34 7030003730 S.RESISTOR ERJ3GEYJ 274 V (270 kΩ)
R35 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ)
R37 7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ)
R38 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
R39 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
R44 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R45 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R46 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R47 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R48 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R49 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R50 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R51 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R52 7030006060 S.RESISTOR ERJ12YJ100H (10 Ω)
R53 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R54 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R55 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R56 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R57 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R58 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R59 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R60 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R61 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R62 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R63 7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ)
R64 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R65 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R66 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R67 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
R68 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
R69 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R70 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330 Ω)
R71 7030006220 S.RESISTOR ERJ12YJ470H (47 Ω)
R73 7030008170 S.RESISTOR ERJ12YJ1R0H (1 Ω)
R75 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R76 7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 kΩ)
R77 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R78 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R79 7030003810 S.RESISTOR ERJ3GEYJ 125 V (1.2 MΩ)
R80 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R82 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R83 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R84 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R85 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R86 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R87 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R88 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R89 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R90 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330 Ω)
R91 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R92 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R93 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R94 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R95 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R96 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R97 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R98 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R99 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R100 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R101 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R102 7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω)
R103 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R104 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R105 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ)
R106 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R107 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R108 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R109 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
REF ORDER
DESCRIPTION
NO. NO.
[MAIN UNIT]
