Screw abbreviations: PH: Pan head BT: Self-tapping ZK: Black
6 - 1
SECTION 6 MECHANICAL PARTS AND DISASSEMBLY
[CHASSIS PARTS] [CHASSIS PARTS]
6-1 FRAME DISASSEMBLY
J1 6510000410 Connector MR-DS-E 02 1
J2 6510000410 Connector MR-DS-E 02 1
J3 6510009290 Connector MR-DSE-02(AG) 1
J4 6510009290 Connector MR-DSE-02(AG) 1
J5 6510009290 Connector MR-DSE-02(AG) 1
J6 6510009290 Connector MR-DSE-02(AG) 1
W5 8900005410 Cable OPC-521 1
W16 8900005410 Cable OPC-521 1
W17 8900005410 Cable OPC-521 1
W18 8900005410 Cable OPC-521 1
W20 8900005380 Cable OPC-525 (N:10 L:400) 1
W21 8900007260 Cable OPC-712 (N:10 L:500) 1
W31 8900008030 Cable OPC-769 [USA], [EUR] 2
W32 8900008210 Cable OPC-805 1
EP8 0880000320 PX-1981 USA Attachment unit [USA] 1
0880000330 PX-1981 EUR Attachment unit [EUR] 1
0880000570 PX-1981
EUR-1 Attachment unit[EUR-1]
1
EP9 6910000310 B312D Isolating bush [USA], [EUR] 2
EP11 6910000310 B312D Isolating bush 2
EP13 6910010480 DL-7C OR-31-15-19H 5
MP1 8210014270 1900 Front panel 1
MP2 8110006231 1900 A-cover-1 1
MP3 8010017072 1900 A-sub chassis-2 1
MP4 8210014952 1900 A-rear panel-2 1
MP5 8010017080 1900 A-cent chassis 1
MP6 8110006243 1900 A-bottom cover-3 1
MP7 8010017091 1900 A-side chassis-1 1
MP8 8930042540 1900 Jack plate 2
MP10 8510011342 1900 A-filter case-2 1
MP11 8510011360 1900 A-filter cover 1
MP12 8310039540 1900 hole plate 1
MP16 8810009620 Bind screw BT M3 × 6 ZK 1
MP17 8810009620 Bind screw BT M3 × 6 ZK 3
MP21 8810003160 Set screw A M3 × 64
MP23 8810003160 Set screw A M3 × 64
MP26 8810003160 Set screw A M3 × 611
MP30 8810004430 Screw PH M3 × 6 ZK 8
MP31 8810004430 Screw PH M3 × 6 ZK 4
MP32 8810009620 Bind screw BT M3 × 6 ZK 1
MP33 8810009620 Bind screw BT M3 × 6 ZK 1
MP34 8810009620 Bind screw BT M3 × 6 ZK 1
MP35 8810009620 Bind screw BT M3 × 6 ZK 1
MP36 8810009620 Bind screw BT M3 × 6 ZK 4
MP37 8810009620 Bind screw BT M3 × 6 ZK 2
MP38 8810009620 Bind screw BT M3 × 6 ZK 1
MP39 8810009620 Bind screw BT M3 × 6 ZK 1
MP40 8810009620 Bind screw BT M3 × 6 ZK 1
MP41 8810009620 Bind screw BT M3 × 6 ZK 2
MP42 8810009620 Bind screw BT M3 × 6 ZK 7
MP45 8810009620 Bind screw BT M3 × 6 ZK 5
MP46 8810008660 Bind screw BT M3 × 8 ZK 4
MP48 8810004430 Screw PH M3 × 6 ZK 2
MP49 8810008690 Screw PH BT M4 ×16 NI-ZU 5
MP52 8810009620 Bind screw BT M3 × 6 ZK 4
MP53 8810009620 Bind screw BT M3 × 6 ZK 6
MP54 8810009620 Bind screw BT M3 × 6 ZK 2
MP55 8810009620 Bind screw BT M3 × 6 ZK 2
MP56 8810009350 Screw PH B0 M3 × 8 SUS ZK 2
MP57 8810009620 Bind screw BT M3 × 6 ZK 3
MP59 8810009620 Bind screw BT M3 × 6 ZK 2
MP61 8810004300 Screw PH M3 ×10 ZK 2
MP63 8810009620 Bind screw BT M3 × 6 ZK 4
MP64 8810004430 Screw PH M3 × 6 ZK 4
MP65 8810008450 Bind screw M4 × 8 ZK 4
MP66 8810008450 Bind screw M4 × 8 ZK 2
MP67 8810008450 Bind screw M4 × 8 ZK 2
MP68 8830000360 Wing nut M5 NI 1
MP69 8850000150 Flat washer M5 NI BS 3
MP70 8830000210 Nut M5 NI BS 1
MP71 8850000440 Spring washer M 5 NI 1
MP72 8930011680 Rubber standoff (G) 5
MP73 8930037420 Rubber sheet (P) 2
MP74 8810009620 Bind screw BT M3 × 6 ZK 1
MP75 8810009620 Bind screw BT M3 × 6 ZK 2
MP76 8810003360 Set screw C M3 × 61
MP77 8810003360 Set screw C M3 × 61
MP78 8810003360 Set screw C M3 × 61
MP79 8810003360 Set screw C M3 × 61
MP80 8810003360 Set screw C M3 × 61
MP81 8810003360 Set screw C M3 × 61
MP82 8810003360 Set screw C M3 × 61
MP83 8810003360 Set screw C M3 × 61
MP84 8810003360 Set screw C M3 × 61
MP85 8810003360 Set screw C M3 × 61
MP86 8310044320 IC-
PW1 FCC sirial number seal [USA]
1
8310039900 IC-
PW1 FCC sirial number seal EUR]
1
8310046130 IC-
PW1 FCC sirial number seal [EUR-1]
1
MP87 8810009620 Bind screw BT M3 × 6 ZK 3
MP88 8810009620 Bind screw BT M3 × 6 ZK 1
MP90 8930046310 1900 A-sheet 1
MP95 8930037280 Poli-cap type M 4
MP96 8930038820 Alumi-sheet V 1
MP97 8930047150 1900 A-side sheet 1
MP98 8930047160 1900 B-side sheet 1
MP99 8930047170 Isolating plate FH 2
MP100 8930047140 Isplating plate FI 1
MP104 8810008660 Screw PH BT M3 × 8 NI-ZU 1
MP105 8810008660 Screw PH BT M3 × 8 NI-ZU 1
MP106 6910008240 59TN4772 1
MP109 8930001170 Grounding spring (A) 1
MP110 8510011840 1900 A-shield plate 1
MP111 8930047270 Sponge (FH) 3
MP112 8930047280 Sponge 1
MP113 8930047260 Himeron sheet (BV) 1
MP114 8930047440 Isolating plate 2
MP116 6910008240 59TN4771 1
MP117 8930046320 1900 B-Sheet 1
MP119 8810009310 Screw FH BT M3 × 6 NI-ZU 1
MP120 8810009620 Bind screw BT M3 × 6 ZK 1
MP121 8810009620 Bind screw BT M3 × 6 ZK 2
WS1 8970022801 EX1900
Special coaxial cable-1 (2)/CH
1
WS3 8970022520 EX1900 1.5D coaxial cable (2)/CH 1
REF NO.
ORDER
NO.
DESCRIPTION
QTY.
REF NO.
ORDER
NO.
DESCRIPTION
QTY.
To Next Page
