Icom IC-PW1 Service Manual

S.=Surface mount
D1 1750000270 S.DIODE 1SS301 (TE85R)
D2 1750000270 S.DIODE 1SS301 (TE85R)
D3 1750000290 S.DIODE 1SS300 (TE85R)
D4 1750000290 S.DIODE 1SS300 (TE85R)
D5 1730002320 S.ZENER MA8051-M (TX)
D6 1750000270 S.DIODE 1SS301 (TE85R)
D7 1750000290 S.DIODE 1SS300 (TE85R)
D8 1750000270 S.DIODE 1SS301 (TE85R)
D10 1750000230 S.DIODE 1SS315 TPH-3
D11 1750000230 S.DIODE 1SS315 TPH-3
L1 6200003260 S.COIL NL 322522T-101J
L2 6200003260 S.COIL NL 322522T-101J
L3 6200003260 S.COIL NL 322522T-101J
L4 6200003260 S.COIL NL 322522T-101J
L5 6200003950 S.COIL HF50ACC 322513-T
L6 6200003950 S.COIL HF50ACC 322513-T
L7 6200003260 S.COIL NL 322522T-101J
L8 6200003260 S.COIL NL 322522T-101J
R1 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R2 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R3 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R4 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R5 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R6 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R7 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R8 7030003330 S.RESISTOR ERJ3GEYJ 121 V (120 Ω)
R9 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R10 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R11 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R12 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R13 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R14 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R15 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R16 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R17 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R18 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R19 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R20 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R21 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R22 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R23 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R24 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R25 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R26 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R27 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R29 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R30 7030008190 S.RESISTOR ERJ12YJ330H (33 Ω)
R31 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R32 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R33 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R34 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R35 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R36 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R37 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R38 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R39 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R40 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R41 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R42 7030006060 S.RESISTOR ERJ12YJ100H (10 Ω)
R43 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R44 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R45 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R46 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R47 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R48 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R51 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R52 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R53 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R54 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R55 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R56 7310002740 S.TRIMMER RV-150 (RH03A3A14X0FC) 103
R57 7310002740 S.TRIMMER RV-150 (RH03A3A14X0FC) 103
R58 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R59 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R60 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R61 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R62 7030009170 S.RESISTOR ERJ1WYJ1R5H (1.5 Ω)
R63 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
5 - 13
REF ORDER
DESCRIPTION
NO. NO.
[SW BOARD]
C1 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C2 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C3 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C4 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C5 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C6 4510005860 S.ELECTROLYTIC ECEV1HA2R2SR
C7 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C8 4510004870 S.ELECTROLYTIC ECEV1CA330P
C9 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C10 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C11 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C16 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C17 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C18 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C19 4510005600 S.ELECTROLYTIC ECEV1CS100SR
C20 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C21 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C24 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C25 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C26 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C27 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C28 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C29 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C30 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C31 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C32 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C33 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C34 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
J1 6510003450 CONNECTOR B09B-EH-S
DS1 5040002080 S.LED CL-200YG-C-TU
DS2 5040002080 S.LED CL-200YG-C-TU
DS3 5040002080 S.LED CL-200YG-C-TU
DS4 5040002080 S.LED CL-200YG-C-TU
DS5 5040002080 S.LED CL-200YG-C-TU
DS6 5040002080 S.LED CL-200YG-C-TU
DS7 5040002080 S.LED CL-200YG-C-TU
DS8 5040001870 S.LED SEC 2462C
DS9 5040002010 S.LED CL-170PG-CD-T
DS10 5040002010 S.LED CL-170PG-CD-T
DS11 5040002010 S.LED CL-170PG-CD-T
DS12 5040002010 S.LED CL-170PG-CD-T
DS13 5040002010 S.LED CL-170PG-CD-T
DS14 5040002010 S.LED CL-170PG-CD-T
DS15 5040002010 S.LED CL-170PG-CD-T
DS16 5040002010 S.LED CL-170PG-CD-T
DS17 5040002010 S.LED CL-170PG-CD-T
DS18 5040002080 S.LED CL-200YG-C-TU
DS19 5040002080 S.LED CL-200YG-C-TU
DS20 5040002010 S.LED CL-170PG-CD-T
DS21 5040002010 S.LED CL-170PG-CD-T
DS22 5040002080 S.LED CL-200YG-C-TU
DS23 5040002080 S.LED CL-200YG-C-TU
DS24 5040002080 S.LED CL-200YG-C-TU
DS26 5040002080 S.LED CL-200YG-C-TU
DS27 5040002080 S.LED CL-200YG-C-TU
S1 2260001890 S.SWITCH SKQDPA
S2 2260001890 S.SWITCH SKQDPA
S3 2260001890 S.SWITCH SKQDPA
S4 2260001890 S.SWITCH SKQDPA
S5 2260001890 S.SWITCH SKQDPA
S6 2260001890 S.SWITCH SKQDPA
S7 2260001890 S.SWITCH SKQDPA
S8 2260001890 S.SWITCH SKQDPA
S9 2260001890 S.SWITCH SKQDPA
W1 7030003860 S.JUMPER ERJ3GE JPW V
W3 7030003860 S.JUMPER ERJ3GE JPW V
W4 7030003860 S.JUMPER ERJ3GE JPW V
W5 7030003860 S.JUMPER ERJ3GE JPW V
W6 7030003860 S.JUMPER ERJ3GE JPW V
W8 7120000380 JUMPER JPW 01 R-01
EP1 0910048766 PCB B 4893F
REF ORDER
DESCRIPTION
NO. NO.
[SW BOARD]
