Icom IC-PW1 Service Manual

5 - 12
S.=Surface mount
L1 6200003260 S.COIL NL 322522T-101J
L2 6200003260 S.COIL NL 322522T-101J
L3 6200003260 S.COIL NL 322522T-101J
L4 6200003260 S.COIL NL 322522T-101J
L5 6200003260 S.COIL NL 322522T-101J
L6 6200003260 S.COIL NL 322522T-101J
R1 7310003820 TRIMMER EVN-D2AA03 B14
R2 7310003820 TRIMMER EVN-D2AA03 B14
C1 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C2 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C3 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C4 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C5 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C6 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
J1 6450001590 CONNECTOR TCS5073-17-4151
J3 6450001130 CONNECTOR JPJ2042-01-110
J4 6450000140 CONNECTOR HSJ0807-01-010
J5 6450001590 CONNECTOR TCS5073-17-4151
J7 6450001130 CONNECTOR JPJ2042-01-110
J8 6450000140 CONNECTOR HSJ0807-01-010
J9 6510019140 S.CONNECTOR 52610-1090
J10 6510003450 CONNECTOR B09B-EH-S
J11 6510003450 CONNECTOR B09B-EH-S
J12 6510018960 S.CONNECTOR B2B-PH-SM3-TB
S1 2220000570 SWITCH HSW1196-01-020
EP1 0910048776 PCB B 4898F
D1 1710000050 DIODE 1SS53
D2 1710000050 DIODE 1SS53
D3 1710000050 DIODE 1SS53
D4 1710000050 DIODE 1SS53
L1 6180000900 COIL LAL 03NA 101K
L2 6180000900 COIL LAL 03NA 101K
L3 6180000900 COIL LAL 03NA 101K
L4 6180000900 COIL LAL 03NA 101K
R1 7540000190 ABSOBER SRYG-2000L
C1 4010006900 CERAMIC HE80SJ YB 472K 50V
C2 4010006900 CERAMIC HE80SJ YB 472K 50V
C3 4010006900 CERAMIC HE80SJ YB 472K 50V
C4 4010006900 CERAMIC HE80SJ YB 472K 50V
C6 4010006900 CERAMIC HE80SJ YB 472K 50V
C7 4010006900 CERAMIC HE80SJ YB 472K 50V
C8 4010006900 CERAMIC HE80SJ YB 472K 50V
C9 4010006900 CERAMIC HE80SJ YB 472K 50V
C11 4010004310 CERAMIC DE0705 SL 100D 1KV
C12 4010004310 CERAMIC DE0705 SL 100D 1KV
C13 4010004310 CERAMIC DE0705 SL 100D 1KV
C14 4010004310 CERAMIC DE0705 SL 100D 1KV
C15 4010004310 CERAMIC DE0705 SL 100D 1KV
C16 4010004310 CERAMIC DE0705 SL 100D 1KV
RL1 6330001460 RELAY FTR-F1CA012V
RL2 6330001460 RELAY FTR-F1CA012V
RL3 6330001460 RELAY FTR-F1CA012V
RL4 6330001460 RELAY FTR-F1CA012V
REF ORDER
DESCRIPTION
NO. NO.
[JACK1 UNIT]
WS1 8600035743 M.OTHER EX1900 P01*J01AN-SW-3
EP1 6910011340 TERMINAL OT-010 M3
EP2 6910011340 TERMINAL OT-010 M3
EP3 0910048716 PCB B 4885F
DS1 5080000380 LAMP HRS-4160A-H9 L150
DS2 5080000380 LAMP HRS-4160A-H9 L150
ME1 5510000470 METER ME-39
ME2 5510000460 METER ME-38
WS1 8970022810 M.OTHER EX1900 J LEAD SET (4)/FR
WS2 8600035961 M.OTHER EX1900 P03*04FR-1
EP1 6910011040 TUBE A-4210-G20
EP2 6910011040 TUBE A-4210-G20
IC1 1130000830 S.IC µPD4094BG-T1
IC2 1130000830 S.IC µPD4094BG-T1
IC3 1130000830 S.IC µPD4094BG-T1
IC4 1130000830 S.IC µPD4094BG-T1
IC5 1110003690 S.IC M62354GP 75EC
IC6 1180001070 S.IC TA7805F (TE16L)
IC7 1130004670 S.IC BU4021BF-T1
IC8 1130007260 S.IC TC7W74FU (TE12L)
IC9 1130005820 S.IC TC4S584F (TE85R)
Q1 1590002310 S.TRANSISTOR DTC114EE TL
Q2 1590002310 S.TRANSISTOR DTC114EE TL
Q3 1590002310 S.TRANSISTOR DTC114EE TL
Q4 1590002310 S.TRANSISTOR DTC114EE TL
Q5 1590002310 S.TRANSISTOR DTC114EE TL
Q6 1590002310 S.TRANSISTOR DTC114EE TL
Q7 1590002310 S.TRANSISTOR DTC114EE TL
Q8 1590002310 S.TRANSISTOR DTC114EE TL
Q9 1590002310 S.TRANSISTOR DTC114EE TL
Q10 1590002310 S.TRANSISTOR DTC114EE TL
Q11 1590002310 S.TRANSISTOR DTC114EE TL
Q12 1590002310 S.TRANSISTOR DTC114EE TL
Q13 1590002310 S.TRANSISTOR DTC114EE TL
Q14 1590002310 S.TRANSISTOR DTC114EE TL
Q15 1590002310 S.TRANSISTOR DTC114EE TL
Q16 1590002310 S.TRANSISTOR DTC114EE TL
Q17 1590002310 S.TRANSISTOR DTC114EE TL
Q18 1590002310 S.TRANSISTOR DTC114EE TL
Q19 1590002310 S.TRANSISTOR DTC114EE TL
Q20 1590002310 S.TRANSISTOR DTC114EE TL
Q21 1590002310 S.TRANSISTOR DTC114EE TL
Q22 1590002310 S.TRANSISTOR DTC114EE TL
Q23 1590002310 S.TRANSISTOR DTC114EE TL
Q24 1590002310 S.TRANSISTOR DTC114EE TL
Q25 1590002310 S.TRANSISTOR DTC114EE TL
Q26 1590002310 S.TRANSISTOR DTC114EE TL
Q27 1590002310 S.TRANSISTOR DTC114EE TL
Q31 1590001940 S.TRANSISTOR DTC144EE TL
Q32 1520000460 S.TRANSISTOR 2SB1132 T100 R
REF ORDER
DESCRIPTION
NO. NO.
[ANT-SW UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[ANT-SW UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[FRONT UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[SW BOARD]
