Icom IC-PW1 Service Manual

S.=Surface mount
L9 6180000990 COIL LAL 04NA 101K
L10 6180000990 COIL LAL 04NA 101K
L11 6110003410 COIL LA-535
L12 6110003400 COIL LA-534
L13 6110003510 COIL LA-544
L14 6110003380 COIL LA-532
L15 6110003370 COIL LA-531
C1 4040000260 BARRIER UZE 08X 104M
C2 4040000260 BARRIER UZE 08X 104M
C3 4040000260 BARRIER UZE 08X 104M
C4 4040000260 BARRIER UZE 08X 104M
C5 4040000260 BARRIER UZE 08X 104M
C6 4040000260 BARRIER UZE 08X 104M
C7 4040000260 BARRIER UZE 08X 104M
C8 4040000260 BARRIER UZE 08X 104M
C9 4040000260 BARRIER UZE 08X 104M
C10 4040000260 BARRIER UZE 08X 104M
C11 4040000150 BARRIER UAT 05X 472K
C12 4040000150 BARRIER UAT 05X 472K
C13 4040000150 BARRIER UAT 05X 472K
C14 4040000150 BARRIER UAT 05X 472K
C15 4040000150 BARRIER UAT 05X 472K
C16 4040000150 BARRIER UAT 05X 472K
C17 4040000150 BARRIER UAT 05X 472K
C18 4040000150 BARRIER UAT 05X 472K
C19 4040000150 BARRIER UAT 05X 472K
C20 4040000150 BARRIER UAT 05X 472K
RL1 6330000570 RELAY AR-39251
RL2 6330000570 RELAY AR-39251
RL3 6330000570 RELAY AR-39251
RL4 6330000570 RELAY AR-39251
RL5 6330000570 RELAY AR-39251
RL6 6330000570 RELAY AR-39251
RL7 6330000570 RELAY AR-39251
RL8 6330000570 RELAY AR-39251
RL9 6330000570 RELAY AR-39251
RL10 6330000570 RELAY AR-39251
WS1 8600035841 M.OTHER EX1900 P01*J01H-1
EP2 6910011340 TERMINAL OT-010 M3
EP3 0910049304 PCB B 5017D
D1 1710000050 DIODE 1SS53
D2 1710000050 DIODE 1SS53
D14 1710000050 DIODE 1SS53
D15 1710000050 DIODE 1SS53
D16 1710000050 DIODE 1SS53
D17 1710000050 DIODE 1SS53
D18 1710000050 DIODE 1SS53
D19 1710000050 DIODE 1SS53
D20 1710000050 DIODE 1SS53
D21 1710000050 DIODE 1SS53
L1 6180000990 COIL LAL 04NA 101K
L2 6180000990 COIL LAL 04NA 101K
L14 6180000990 COIL LAL 04NA 101K
L15 6180000990 COIL LAL 04NA 101K
L16 6180000990 COIL LAL 04NA 101K
L17 6180000990 COIL LAL 04NA 101K
L18 6180000990 COIL LAL 04NA 101K
L19 6180000990 COIL LAL 04NA 101K
L20 6180000990 COIL LAL 04NA 101K
L21 6180000990 COIL LAL 04NA 101K
5 - 11
REF ORDER
DESCRIPTION
NO. NO.
[H-NET BOARD]
C1 4040000150 BARRIER UAT 05X 472K
C2 4040000150 BARRIER UAT 05X 472K
C34 4040000150 BARRIER UAT 05X 472K
C39 4040000150 BARRIER UAT 05X 472K
C40 4010004790 CERAMIC DE1210 SL 680J 6KV
C41 4010004790 CERAMIC DE1210 SL 680J 6KV
C42 4010004790 CERAMIC DE1210 SL 680J 6KV
C43 4010004790 CERAMIC DE1210 SL 680J 6KV
C44 4040000150 BARRIER UAT 05X 472K
C45 4010004300 CERAMIC DE1410 SL 221J 3KV
C46 4010004300 CERAMIC DE1410 SL 221J 3KV
C47 4010004300 CERAMIC DE1410 SL 221J 3KV
C48 4010004300 CERAMIC DE1410 SL 221J 3KV
C49 4040000150 BARRIER UAT 05X 472K
C50 4010004810 CERAMIC DE1310 SL 101J 6KV
C51 4010004810 CERAMIC DE1310 SL 101J 6KV
C52 4010004810 CERAMIC DE1310 SL 101J 6KV
C53 4010004810 CERAMIC DE1310 SL 101J 6KV
C54 4040000150 BARRIER UAT 05X 472K
C55 4010004710 CERAMIC DE0707 SL 150J 3KV
C56 4010004710 CERAMIC DE0707 SL 150J 3KV
C57 4010004710 CERAMIC DE0707 SL 150J 3KV
C58 4010004710 CERAMIC DE0707 SL 150J 3KV
C59 4040000150 BARRIER UAT 05X 472K
C60 4010004800 CERAMIC DE1210 SL 820J 6KV
C61 4010004800 CERAMIC DE1210 SL 820J 6KV
C62 4010004800 CERAMIC DE1210 SL 820J 6KV
C63 4010004800 CERAMIC DE1210 SL 820J 6KV
C64 4040000150 BARRIER UAT 05X 472K
C65 4010004810 CERAMIC DE1310 SL 101J 6KV
C66 4010004810 CERAMIC DE1310 SL 101J 6KV
C67 4010004810 CERAMIC DE1310 SL 101J 6KV
C68 4010004810 CERAMIC DE1310 SL 101J 6KV
C69 4040000150 BARRIER UAT 05X 472K
C70 4010004830 CERAMIC DE1510 SL 151J 6KV
C71 4010004830 CERAMIC DE1510 SL 151J 6KV
C72 4010004830 CERAMIC DE1510 SL 151J 6KV
C73 4010004830 CERAMIC DE1510 SL 151J 6KV
C74 4010004710 CERAMIC DE0707 SL 150J 3KV
C75 4010004710 CERAMIC DE0707 SL 150J 3KV
C76 4010004710 CERAMIC DE0707 SL 150J 3KV
C77 4010004710 CERAMIC DE0707 SL 150J 3KV
C82 4010004810 CERAMIC DE1310 SL 101J 6KV
C84 4010004810 CERAMIC DE1310 SL 101J 6KV
C86 4010004810 CERAMIC DE1310 SL 101J 6KV
C87 4010004810 CERAMIC DE1310 SL 101J 6KV
C88 4010004810 CERAMIC DE1310 SL 101J 6KV
C89 4010004810 CERAMIC DE1310 SL 101J 6KV
C90 4010004710 CERAMIC DE0707 SL 150J 3KV
C91 4010004710 CERAMIC DE0707 SL 150J 3KV
C92 4010004710 CERAMIC DE0707 SL 150J 3KV
C93 4010004710 CERAMIC DE0707 SL 150J 3KV
C94 4010004710 CERAMIC DE0707 SL 150J 3KV
C95 4010004710 CERAMIC DE0707 SL 150J 3KV
C96 4010004710 CERAMIC DE0707 SL 150J 3KV
C97 4010004710 CERAMIC DE0707 SL 150J 3KV
RL1 6330001440 RELAY VS-12TBU-VD3
RL2 6330001440 RELAY VS-12TBU-VD3
RL3 6330000570 RELAY AR-39251
RL4 6330001490 RELAY VB-12MBU-UC (UL3)
RL5 6330001490 RELAY VB-12MBU-UC (UL3)
RL6 6330001490 RELAY VB-12MBU-UC (UL3)
RL7 6330000570 RELAY AR-39251
RL8 6330001490 RELAY VB-12MBU-UC (UL3)
RL9 6330001490 RELAY VB-12MBU-UC (UL3)
RL10 6330001490 RELAY VB-12MBU-UC (UL3)
WS1 8600035851 M.OTHER EX1900 P01*J01C-1
WS2 8600035861 M.OTHER EX1900 P02*J02C-1
EP3 0910049245 PCB B 5019E
REF ORDER
DESCRIPTION
NO. NO.
[C-NET BOARD]
REF ORDER
DESCRIPTION
NO. NO.
[C-NET BOARD]
