6 - 4
[FRONT UNIT]
DS1 5080000380 Lamp HRS-4160A-H9 L150 1
DS2 5080000380 Lamp HRS-4160A-H9 L150 1
EP1 6910011040 Tube A-4210-G20 1
EP2 6910011040 Tube A-4210-G20 1
ME1 5510000470 Meter ME-39 EX1900 1
ME2 5510000460 Meter ME-38 1
MP1 8210014260 1900 Control panel 1
MP2 8110006101 1900 Control cover-1 1
MP3 8610008431 Knob K202-1 1
MP4 8610010371 Knob K155(A)-1 EX1900 2
MP5 8610010381 Knob K155(B)-1 EX1900 1
MP6 8610010391 Knob K155(C)-1 EX1900 1
MP8 8610010411 Knob K200(B)-1 EX1900 4
MP11 8930042550 1900 Meter angle 2
MP12 8930017960 Push spring 9
MP13 8930041660 Standoff cushion (B) 4
MP14 8010002990 Meter holder 2
MP15 8810004430 Screw PH M3 × 6 ZK 5
MP16 8810008660 SCREW PH BT M3 × 8 NI-ZU 6
MP17 8810008660 SCREW PH BT M3 × 8 NI-ZU 4
MP18 8810002250 SCREW FH B0 M2.6 × 64
MP19 8930006630 Himeron sheet G 2
MP20 8930043290 Rubber sheet (AF) 4
WS1 8970022810 EX1900 J lead set (4)/FR 4
WS2 8600035961 EX1900 P03*04FR-1 1
REF NO.
ORDER
NO.
DESCRIPTION
QTY.
6-2 FRONT UNIT DISASSEMBLY
[COMBINR UNIT]
J1 6510017920 Connector 1811P342 1
J2 6510017920 Connector 1811P342 1
J3 6510017920 Connector 1811P342 1
J4 6510017920 Connector 1811P342 1
J5 6510003080 Connector RT01T-1.0B 1
J6 6510003080 Connector RT01T-1.0B 1
J7 6510003080 Connector RT01T-1.0B 1
J7 6510003080 Connector RT01T-1.0B 1
L5 6140003290 LR-365 1
EP1 6910011330 Terminal OT-009 M3 1
EP2 6910011330 Terminal OT-009 M3 1
EP5 0910049250 B5039 (#1900-3D) 1
MP1 8930000700 Tread spacer (T) 1
MP2 8810003380 Set screw C M3 ×10 2
WS1 8970022610 EX1900 0.8D coaxial cable (3)/CO 1
WS2 8600035730 EX1900 P01*J08CO 1
REF NO.
ORDER
NO.
DESCRIPTION
QTY.
[FILTER UNIT]
EP1 6910011330 Terminal OT-009 M3 1
EP2 6910011330 Terminal OT-009 M3 1
EP3 6910011330 Terminal OT-009 M3 1
EP4 6910011330 Terminal OT-009 M3 1
MP1 8930014140 Grounding spring(D) 1
MP4 8930014140 Grounding spring(D) 1
MP5 8510011480 1900 AL cover 1
RL1 6330000201 Relay VS-12TBU-E-UC 1
RL2 6330000201 Relay VS-12TBU-E-UC 1
RL3 6330000201 Relay VS-12TBU-E-UC 1
RL4 6330000201 Relay VS-12TBU-E-UC 1
RL5 6330000201 Relay VS-12TBU-E-UC 1
RL6 6330000201 Relay VS-12TBU-E-UC 1
RL7 6330000201 Relay VS-12TBU-E-UC 1
RL8 6330000201 Relay VS-12TBU-E-UC 1
RL9 6330000201 Relay VS-12TBU-E-UC 1
RL10 6330000201 Relay VS-12TBU-E-UC 1
RL11 6330000201 Relay VS-12TBU-E-UC 1
RL12 6330000201 Relay VS-12TBU-E-UC 1
RL13 6330000201 Relay VS-12TBU-E-UC 1
RL14 6330000201 Relay VS-12TBU-E-UC 1
RL15 6330001500 Relay AW3033 1
RL16 6330001210 Relay VB-12TBU-UC (UL3) 1
RL17 6330001210 Relay VB-12TBU-UC (UL3) 1
WS1 8600035754 EX1900 P01*J01FI-4 1
WS2 8970022640 EX1900 1.5D coaxial cable (1)/FI 1
WS3 8970022650 EX1900 Tefron coaxial cable (1)/FI 1
REF NO.
ORDER
NO.
DESCRIPTION
QTY.
6-3 FILTER UNIT DISASSEMBLY
Screw abbreviations: PH: Pan head
BT, B0: Self-tapping
ZK: Black
NI-ZU: Nickel-Zinc
To Next Page
