1 - 1
M GENERAL
• Frequency range : 1.800–1.999 MHz
3.500–3.999 MHz
4.630 MHz
7.000–7.300 MHz
10.100–10.150 MHz
14.000–14.350 MHz
18.068–18.168 MHz
21.000–21.450 MHz
24.890–24.990 MHz*
1
28.000–29.700 MHz*
1
50.000–54.000 MHz
*
1
The USA version can only be used the antenna tuner on the 24–28 MHz bands.
• Duty cycle : Full duty
• Input connector : SO-239 × 2 (50 )
• Output connector : SO-239 × 4 (50 )
• Power supply voltage : 90 V–132 V AC or 180 V–264 V AC
(single-phase; 50/60 Hz)
• Usable temperature range : –10 ˚C to +40 ˚C; +14 ˚F to +104 ˚F
• Dimensions : Linear amplifier 350(W)×265(H)×375(D) mm;
(Projections not included) 13.78(W)×10.43(H)×14.76(D) in
Remote controller 205(W)×71(H)×68.3(D) mm;
8.07(W)×2.80(H)×2.69(D) in
• Weight : 25 kg; 55.12 lb (Included in the remote controller)
(Included in the remote controller)
M LINEAR AMPLIFIER
• Output power :
*
1
EUR-1 version is 450–550 W;
*
2
EUR-1 version is 450–550 W PEP
• Driving power : Max. 100 W
• Sprious emissions : Less than –60 dB (for HF bands)
Less than –70 dB (for 50 MHz band)
M ANTENNA TUNER
• Output matching range : 16.7–150.0 *
1
(for HF bands)
20.0–125.0 (for 50 MHz band)
*
1
Specifications of 1.9 MHz band guaranteed 1.85–1.95 MHz
Auto tuning accuracy : VSWR 1.5:1 or less
• Min. required input power : 60 W
• Insertion loss : Less than 1 dB (after tuning)
SECTION 1 SPECIFICATIONS
All stated specifications are subject to change without notice or obligation.
MODE
CW, RTTY
SSB
INPUT AC VOLTAGE
90–132 V AC
450–600 W
*
1
450–600 W PEP*
2
180–264 V AC
950–1150 W
950–1150 W PEP
