Icom ID-51E

5 - 6
5-3 TRANSMIT ADJUSTMENT (Continued)
• TRANSMIT POWER ADJUSTMENT (at 5.5 V)
Select an adjustment item using
/
, and then set the adjustment value as specifi ed using [DIAL].
ADJUSTMENT
ADJUSTMENT
ITEM
OPERATION VALUE
TRANSMIT
POWER
[PO5]
1 1) Set the power supply voltage to 5.5 V.
2) Connect an RF power meter to the antenna connector.
3) While transmitting, adjust the TX power using [DIAL], and then
push
to store the adjustment value.
80–120 mW
-VHF-
(BAND LOW)
2
(BAND HIGH)
3
-UHF-
(BAND LOW)
4
(BAND HIGH)
5
NOTE: When "IDLING CURRENT" is adjusted, "TRANSMIT POWER" must be also re-adjusted.
• TRANSMIT POWER ADJUSTMENT (at 7.4 V)
Select an adjustment item using
/
, and then set the adjustment value as specifi ed using [DIAL].
ADJUSTMENT
ADJUSTMENT
ITEM
OPERATION VALUE
TRANSMIT POWER 1 1) Set the power supply voltage to 7.4 V.
2) Connect an RF power meter to the antenna connector.
–
-VHF-
(Hi power)
[BAND LOW]
2• While transmitting, adjust the TX power using [DIAL], and then
push
to store the adjustment value.
4.8–5.2 W
[BAND HIGH]
3
-UHF-
(Hi power)
[BAND LOW]
4
[BAND HIGH]
5
-VHF-
(Mid power)
[BAND LOW]
6
2.3–2.7 W
[BAND HIGH]
7
-UHF-
(Mid power)
[BAND LOW]
8
[BAND HIGH]
9
-VHF-
(Low2 power)
[BAND LOW]
10
0.9–1.1 W
[BAND HIGH]
11
-UHF-
(Low2 power)
[BAND LOW]
12
[BAND HIGH]
13
-VHF-
(Low1 power)
[BAND LOW]
14
0.4–0.6 W
[BAND HIGH]
15
-UHF-
(Low1 power)
[BAND LOW]
16
[BAND HIGH]
17
-VHF-
(S-Low power)
[BAND LOW]
18
80–120 mW
[BAND HIGH]
19
-UHF-
(S-Low power)
[BAND LOW]
20
[BAND HIGH]
21
