7 - 1
[CHASSIS PARTS]
REF ORDER
DESCRIPTION
QTY.
NO. NO.
J1 6910015630 2682 ANT CONNECTOR <EIK> 1
SP1 2510001650 K028NA510-13 <OSC> 1
W1 8900014801 OPC-1573-1 (P0.5N10L50) 1
EP1 6910023940 PGS4ER-CX-512 1
MP1 8010022510 3390 CHASSIS 1
MP2 8210028210 3390 FRONT PANEL (A) ASSEMBLY [EUR] 1
8210028210 3390 FRONT PANEL (A) ASSEMBLY [UK] 1
8210028210 3390 FRONT PANEL (A) ASSEMBLY [ITR] 1
8210028200 3390 FRONT PANEL ASSEMBLY [USA] 1
8210028200 3390 FRONT PANEL ASSEMBLY [KOR] 1
8210028200 3390 FRONT PANEL ASSEMBLY [EXP] 1
8210028200 3390 FRONT PANEL ASSEMBLY [EXP-01] 1
8210028200 3390 FRONT PANEL ASSEMBLY [AUS] 1
MP3 8210028020 3390 REAR PANEL 1
MP6 8310080730 3390 WINDOW PLATE 1
MP7 8210028040 3390 REFLECTOR 1
MP8 8930085930 3390 MAIN SEAL 1
MP12 8930076440 3115 VENT SHEET 1
MP13 8930030920 1301 SHEET 1
MP14 8930058550 O-RING (AS) 1
MP15 8930084870 3384 REAR SHEET 1
MP19 8610014360 KNOB N-397 1
MP20 8610014370 KNOB N-398 1
MP21 8930083090 3322 D-BUTTON 1
MP22 8930083070 3322 LENS 1
MP23 8930083140 3322 CONTACT RUBBER (TOT) 1
MP24 8930083881 O-RING (CK)-1 (TOT) 1
MP25 8930083670 O-RING (CL) (TOT) 1
MP26 8930083680 O-RING (CM) (TOT) 1
MP27 8830003670 VR NUT (AC) 1
MP28 8830003660 STEP NUT (M) 1
MP29 8930083700 DOUBLE SIDE TAPE (BM) 1
MP30 8930086950 SPONGE (MD) 1
MP31 8930083810 SPONGE (LJ) 1
MP32 8930083900 INSULATION SHEET (MW) 1
MP33 8930083690 3322 GPS SPONGE 1
MP34 8810010850 PHBT B0 M2X8 SUS SSBC 2
MP35 8810011050 BT M2X3 NI-ZC3 11
MP36 8810011050 BT M2X3 NI-ZC3 6
MP38 8930086021 3322 C-BUTTON (A)-1 1
MP39 8930086030 3390 SD CAP (TOT) 1
MP40 8930086040 3390 JACK CAP (TOT) 1
MP41 8930086050 3322 KEYBOARD (A) <SEP> 1
MP42 8510020580 3390 SHIELD PLATE <KN> 1
MP43 8510020600 3390 DSP CASE <KN> 1
MP44 8930086060 3390 WINDOW SHEET 1
MP45 8930086070 3390 WHITE SHEET 1
MP46 8930086090 DOUBLE SIDE TAPE (BP) 1
MP47 8930086080 3390 MIC SPONGE 1
MP48 8930087760 FERRITE SHEET (AJ) 1
MP49 8930087770 FERRITE SHEET (AK) 1
MP50 8930087220 3390 INSULATION SHEET 1
MP51 8930085100 SHIELD SPONGE (CW) 1
MP52 8930075180 FERRITE SHEET (X) 1
MP53 8930087760 FERRITE SHEET (AJ) 1
MP54 8930088010 3390 LCD PLATE 1
MP55 8930058500 INSULATION SHEET (HB) 1
MP56 8930086090 DOUBLE SIDE TAPE (BP) 1
MP57 8930086090 DOUBLE SIDE TAPE (BP) 1
MP59 8930088200 3390 EARTH PLATE [EUR] 1
8930088200 3390 EARTH PLATE [UK] 1
8930088200 3390 EARTH PLATE [ITR] 1
8930088200 3390 EARTH PLATE [USA] 1
MP60 8930088240 INSULATION SHEET (NC) [EUR] 1
8930088240 INSULATION SHEET (NC) [UK] 1
8930088240 INSULATION SHEET (NC) [ITR] 1
8930088240 INSULATION SHEET (NC) [USA] 1
[MAIN UNIT]
[ACCESSORIES]
REF ORDER
DESCRIPTION
QTY.
NO. NO.
J2* 6450000870 HEC2711-01-020 1
J3* 6510028130 AXK5S50047YG 1
J4* 6510025880 TC38-108-01 <CFE> 1
J5* 6450000131 HSJ1102-018540 1
J450* 6510029520 AXK5F12347YG 1
J451* 6510029520 AXK5F12347YG 1
S2* 2260001900 SW-149 (SKHLLD) 1
EP21* 6910023540 N010M9-01C000CR <CCP> 1
EP22* 6910023540 N010M9-01C000CR <CCP> 1
MP1 8950007850 3322 CONTACT SPRING <CCP> 1
MP8* 8410002610 2888 PA HEATSINK Y835 1
MP9* 8510017841 OG-321610GK 1
MP10* 8510017841 OG-321610GK 1
MP11* 8510017841 OG-321610GK 1
MP12* 8510017841 OG-321610GK 1
MP13* 8510017841 OG-321610GK 1
[VCO1 UNIT]
REF ORDER
DESCRIPTION
QTY.
NO. NO.
J1* 6510029530 AXK6F12347YG 1
MP1 8510020590 3390 VCO CASE <KN> 1
REF ORDER
DESCRIPTION
QTY.
NO. NO.
EP1 6910018620 BLACK HANDY STRAP 1
EP2 3310002150 FA-S270C 1
EP3 (Optional) BC-167SD [EUR] 1
(Optional) BC-167SD [ITR] 1
(Optional) BC-167SA [USA] 1
(Optional) BC-167SD [KOR] 1
(Optional) BC-167SA [EXP] 1
(Optional) BC-167SD [EXP-01] 1
(Optional) BC-167SV [AUS] 1
EP4 (Optional) BP-271 1
MP1 (Optional) MB-127 1
[VCO2 UNIT]
REF ORDER
DESCRIPTION
QTY.
NO. NO.
J1* 6510029530 AXK6F12347YG 1
MP1 8510020590 3390 VCO CASE <KN> 1
[LOGIC UNIT]
REF ORDER
DESCRIPTION
QTY.
NO. NO.
J2* 6510028080 27FHSY-RSM1-GAN-TB (LF) (SN) 1
J3* 6510028170 SDHL-8BNS-K-363-A0-ETB (HF) 1
J4* 6510024580 HSJ1621-019011 1
J5* 6510028920 AXK6S50647YG 1
J271* 6510028880 04-6238-010-410-800 1
DS13 5030003660 M1-1677TFF-4 <TES> 1
MC1* 7700002850 EM6022P-65B-G <HOR> 1
S1* 2260003300 EVQPQHB55 1
S2* 2260003300 EVQPQHB55 1
S3* 2260003300 EVQPQHB55 1
S4* 2260003300 EVQPQHB55 1
S5* 2260003300 EVQPQHB55 1
S6* 2260003300 EVQPQHB55 1
S7* 2260003300 EVQPQHB55 1
S8* 2260003300 EVQPQHB55 1
S9* 2260003300 EVQPQHB55 1
S10* 2260003300 EVQPQHB55 1
S11* 2260003300 EVQPQHB55 1
S12 2250000710 F082EN7510W-1 1
S13* 2260003320 SKRTLAE010 1
S14* 2260003320 SKRTLAE010 1
BT1* 3020000390 ML414HIV01E 1
SECTION 7
MECHANICAL PARTS
*: Refer to “BOARD LAYOUTS” for the location.
**: Refer to “GENERAL WIRING” for the connection
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
