Always use an electrical outlet that is protected by Residual Current Device (RCD)
Safety Switch with a trip current of 30mA or less. A Safety switch is required by
Australian/New Zealand Standard AU/NZS 60335.1-2011.
If the supply cord is damaged, it must be replaced by a special cord or assembly
available from White International Pty Ltd or its service agent.
The iCON NXT Pro is supplied with a 10 amp rated lead and AS/NZ 3112 (Type 1) 3 pin
male power plug for connecting to mains power.
The ‘Plug and Play’ version of the iCON NXT Pro is fitted with a 10 amp rated IEC C13
appliance connector.
When the iCON NXT Pro is purchased as CONTROLLER ONLY it is supplied with a 2 core
and earth power cable for connection to the pump’s electric motor. This must be connected
by a suitably qualified technician.
An optional 15 Amp rated power cord kit is available as an accessory.
There is an additional earth wire inside the controller
which provides protection in the event of flooding.
