2.2 Front Panel
1. Infrared receiver window
2. VFD display area
3. Power indicator & button
Mode Status
Working Blue
Standby Red
2.3 Side Panel
2.4 Back Panel
1. ‘U’ button, used to firmware
upgrade
2. A/V OUT jack
3. Y/Pb/Pr OUT jack
4. HDMI interface
5. Gigabit LAN socket
6. S/PDIF Optical jack
7. S/PDIF Coaxial jack
8. Power input
1. Memory Card slot
2. USB 2.0 HOST port
3. USB 3.0 Device port
