FX21 User Manual V5.01+ 14Dec07 Page 9
*DRAFT WGTS : I = average weight of animals in High Group
D = average weight of animals in Centre Group
M = average weight of animals in Low Group
*DRAFT TOT : upuBM/I = total weight of animals in High Group
upuBM/D = total weight of animals in Centre Group
upuBM/M = total weight of animals in Low Group
*AVG SCORE : displays the average condition score for the selected group, taking into
account only non-zero scores.
For example : TD 6/7
QUICK EXIT
Whenever statistics are flashing, you may press the key for a quick exit back to the
weighing mode. ’Foe’ is displayed.
“WHAT IF” DRAFTING STATISTICS
Since statistics are recalculated on entry, you may change the draft limits and re-examine
the drafting statistics to determine how many animals would have been drafted into each
weight range with different settings.
ICONIX FX PRINTER OPTION
The Iconix FX Printer is a rugged, portable printer that uses standard adding machine
paper rolls. It is powered from the internal battery of the FX21 indicator.
NOTE: The FX21 must be set to a baud rate of 4800 when using the FX Printer. See the
Set-Up section for details on how to do this.
For a printed copy of statistics or records, plug the printer into the connector labelled
‘Optional I/O’ at the back of the indicator.
Press , then *PRINT RECS to print all records in memory for the selected group
(arranged with tag numbers in numeric order).
Press , then *PRINT STATS for a full statistics printout for the selected group.
If a printout is required of all records in memory, or the statistics for all records, select
Group 0 before doing the printouts. See USING ALL GROUPS above.
IMPORTANT NOTE:
The ‘Optional I/O’ connector is reserved for the use with the Iconix FX Printer and the
Iconix Auto-Draft Controller. DO NOT ATTACH ANY OTHER EQUIPMENT, as damage
to the FX21 and/or the other equipment is very likely.
