FX21 User Manual V5.01+ 14Dec07 Page 11
4. SET-UP
NOTE : The FX21 system has been factory-configured to optimum settings for the
majority of applications. It is strongly recommended that these settings are left as
is, unless there is a good reason for making a change. Please contact your dealer,
distributor or Iconix for advice if necessary.
NOTE : Ensure that the correct set of loadbars or platform is connected to the FX21
indicator before attempting to change any set-up parameters. There are three possible
scale types that are automatically recognised when plugged in, as shown by the Scale
1,2,3 annunciators on the right of the display. All of the set-up parameters are
independently set and stored for each scale type.
For access to set-up, press the WEIGH key and keep it held down while switching the
FX21 ON. As soon as ’TFu’ is displayed, release the WEIGH key, then press ZERO.
The parameters are accessed in the following order:
1. AUTO-DRAFT ’esGu/PG’ if disabled
’esGu/Po’ for normal speed
’esGu/IT’ for high speed
Use the ZERO key to change the setting.
To accept the displayed setting and step on to the next parameter, press WEIGH.
The auto-drafting feature allows use of the FX21 with sheep drafting units from
Racewell Industries Ltd. For new model Racewell crates (these have 4 infrared “eyes”
fitted), select the high speed auto-draft mode. The high speed mode should NOT be
used for older model Racewell crates.
When auto-drafting is enabled, additional drafting functions are available via the FX21
keyboard.
2. ZERO-TRACKING ’[FsP/Po’ if enabled
’[FsP/PG’ if disabled
Use the ZERO key to change the setting.
To accept the displayed setting and step on to the next parameter, press WEIGH.
Zero-tracking is a feature which automatically restores the scale to zero, by “tracking
out” small amounts of dung and dirt left on the scale. It should be enabled for most
weighing applications.
3. DUPLICATE TAG NUMBER CHECKING ’eVQM/Po’ if enabled
’eVQM/PG’ if disabled
Use the ZERO key to change the setting.
To accept the displayed setting and step on to the next parameter, press WEIGH.
When Duplicate Checking is enabled, after entering a tag number, when WEIGH is
pressed all records in the selected Group are checked for previous use of the same
(non-zero) tag number.
