Page 12 FX21 User Manual V5.01+ 14Dec07
4. BAUD RATE SETTING
Select from the range 1200, 2400, 4800, 9600, 19200, 38400, 57600.
’c/2:311’ for example
Use the ZERO key to change the setting.
To accept the displayed setting and step on to the next parameter, press WEIGH.
Baud rate is the rate of data transfer via the RS232 serial port. The FX21 is factory set
to 19200 for high speed data transfer when uploading records to a computer with the
Iconix WinFX Linker programme. It must be changed to 4800 for use with the Iconix FX
Printer.
5. DISPLAY RELEASE ’sFMT/Po’ if enabled
’sFMT/PG’ if disabled
Use the ZERO key to change the setting.
To accept the displayed setting and step on to the next parameter, press WEIGH.
The standard factory setting is Display Release OFF, which in HOLD mode keeps the
last weighing locked on the display, until the next weighing. For Display Release ON,
when the animal that has been weighed is moved from the scale, the displayed weight
will not remain locked on the display.
6. WEIGHT UNITS ’IH’ for kilograms
’Mc’ for pounds
Use the ZERO key to change the setting.
To accept the displayed setting and step on to the next parameter, press WEIGH.
The standard factory setting is kg. If pounds are selected, the scale calibration is
changed accordingly, and printouts will show LB.
7. LANGUAGE ’FoHMTI’ for English
’FTQBoM’ for Spanish
’eFVuti’ for German
’GsBoDF’ for French
Use the ZERO key to change the setting.
To accept the displayed setting, press WEIGH.
The display messages and printouts are shown in the selected language. There are
English, Spanish, German and French versions of the front panel decal. The language
setting should match the decal.
After the Language setting has been viewed or modified, WEIGH is pressed for the
final time.
’TBvFe’ is displayed while the settings are being stored, before
returning to the normal weighing mode.
