Table 10 -- Dry Coil Air Delivery* -- Horizontal and Downflow Discharge -- Sizes 24-- 60 208/230VAC -- 1 Phase (Cont.)
Unit
Size
Heating Rise
Range
o
F(
o
C)
Motor
Speed
Wire
Color
External Static Pressure (IN. W.C.)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
42060
25 --- 55
( 14 --- 3 1)
Low
3
Blue
CFM 1001 902 833 777 717 650 575 527 466 419 BHP 0.13 0.13 0.14 0.14 0.15 0.16 0.17 0.18 0.19 0.20 Heat Rise (
o
F) 45 50 54 NA NA NA NA NA NA NA
Heat Rise (
o
C) 25 28 30 NA NA NA NA NA NA NA
M e d --- L o w
1
Pink
CFM 1016 950 902 842 783 721 655 590 541 480 BHP 0.13 0.14 0.15 0.16 0.17 0.18 0.19 0.20 0.21 0.22 Heat Rise (
o
F) 44 47 50 53 NA NA NA NA NA NA
Heat Rise (
o
C) 25 26 28 30 NA NA NA NA NA NA
Medium
2
Red
CFM 1403 1358 1316 1265 1217 1167 1116 1067 1012 956 BHP 0.29 0.30 0.31 0.33 0.34 0.35 0.36 0.37 0.38 0.39 Heat Rise (
o
F) 32 33 34 35 37 38 40 42 44 47
Heat Rise (
o
C) 18 18 19 20 20 21 22 23 25 26
M e d --- H i g h Orange
CFM 1461 1411 1367 1327 1275 1220 1174 1127 1074 1022 BHP 0.32 0.33 0.35 0.36 0.37 0.38 0.39 0.40 0.41 0.42 Heat Rise (
o
F) 31 32 33 34 35 37 38 40 42 44
Heat Rise (
o
C) 17 18 18 19 20 20 21 22 23 24
High Black
CFM 1575 1528 1488 1447 1406 1360 1314 1264 1213 1159 BHP 0.40 0.42 0.43 0.44 0.45 0.46 0.47 0.48 0.49 0.50 Heat Rise (
o
F) 28 29 30 31 32 33 34 35 37 39
Heat Rise (
o
C) 16 16 17 17 18 18 19 20 21 21
42090
35 --- 65
( 19 --- 3 6)
Low
3
Blue
CFM 1001 902 833 777 717 650 575 527 466 419 BHP 0.13 0.13 0.14 0.14 0.15 0.16 0.17 0.18 0.19 0.20 Heat Rise (
o
F) NA NA NA NA NA NA NA NA NA NA
Heat Rise (
o
C) NA NA NA NA NA NA NA NA NA NA
Med---Low Pink
CFM 1016 950 902 842 783 721 655 590 541 480 BHP 0.13 0.14 0.15 0.16 0.17 0.18 0.19 0.20 0.21 0.22 Heat Rise (
o
F) NA NA NA NA NA NA NA NA NA NA
Heat Rise (
o
C) NA NA NA NA NA NA NA NA NA NA
Medium
2
Red
CFM 1403 1358 1316 1265 1217 1167 1116 1067 1012 956 BHP 0.29 0.30 0.31 0.33 0.34 0.35 0.36 0.37 0.38 0.39 Heat Rise (
o
F) 48 50 51 53 56 58 61 63 NA NA
Heat Rise (
o
C) 27 28 29 30 31 32 34 35 NA NA
Med---High
1
Orange
CFM 1461 1411 1367 1327 1275 1220 1174 1127 1074 1022 BHP 0.32 0.33 0.35 0.36 0.37 0.38 0.39 0.40 0.41 0.42 Heat Rise (
o
F) 46 48 49 51 53 55 58 60 63 NA
Heat Rise (
o
C) 26 27 27 28 29 31 32 33 35 NA
High Black
CFM 1575 1528 1488 1447 1406 1360 1314 1264 1213 1159 BHP 0.40 0.42 0.43 0.44 0.45 0.46 0.47 0.48 0.49 0.50 Heat Rise (
o
F) 43 44 45 47 48 50 51 54 56 58
Heat Rise (
o
C) 24 25 25 26 27 28 29 30 31 32
