ICP PGD4 E Series - Page 38

38 46201200402
Specifications are subject to change without notice.
Table 11 -- Dry Coil Air Delivery* -- Horizontal Discharge -- Sizes 36--60 3 Phase Models Only (Cont.)
Unit
Heating
Rise Range
Motor
Speed
Wire
Color
External Static Pressure (IN. W.C.)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9
42060
25 --- 55
o
F
(14 --- 31
o
C)
Low Blue
CFM 952 882 806 746 671 605 530 551 486
Heating Rise (
o
F) 46 49 54 NA NA NA NA NA NA
Heating Rise (
o
C) 25 27 30 NA NA NA NA NA NA
Med---Low
1
Pink
CFM 1002 936 875 821 748 687 613 554 565
Heating Rise (
o
F) 43 46 50 53 NA NA NA NA NA
Heating Rise (
o
C) 24 26 28 29 NA NA NA NA NA
Medium Red
CFM 1255 1210 1145 1074 1008 940 878 895 838
Heating Rise (
o
F) 35 36 38 40 43 46 49 48 52
Heating Rise (
o
C) 19 20 21 22 24 26 27 27 29
M e d --- H i g h
2
Orange
CFM 1335 1267 1246 1176 1109 1049 988 926 872
Heating Rise (
o
F) 32 34 35 37 39 41 44 47 50
Heating Rise (
o
C) 18 19 19 20 22 23 24 26 28
High Black
CFM 1472 1401 1326 1251 1275 1198 1139 1085 1023
Heating Rise (
o
F) 29 31 33 35 34 36 38 40 42
Heating Rise (
o
C) 16 17 18 19 19 20 21 22 24
42090
35 --- 65
o
F
(19 --- 36
o
C)
Low Blue
CFM 952 882 806 746 671 605 530 551 486
Heating Rise (
o
F) NA NA NA NA NA NA NA NA NA
Heating Rise (
o
C) NA NA NA NA NA NA NA NA NA
Med---Low Pink
CFM 1002 936 875 821 748 687 613 554 565
Heating Rise (
o
F) NA NA NA NA NA NA NA NA NA
Heating Rise (
o
C) NA NA NA NA NA NA NA NA NA
Medium
1
Red
CFM 1255 1210 1145 1074 1008 940 878 895 838
Heating Rise (
o
F) 53 55 58 62 NA NA NA NA NA
Heating Rise (
o
C) 30 31 32 35 NA NA NA NA NA
M e d --- H i g h
2
Orange
CFM 1335 1267 1246 1176 1109 1049 988 926 872
Heating Rise (
o
F) 50 53 54 57 60 64 NA NA NA
Heating Rise (
o
C) 28 29 30 32 34 35 NA NA NA
High Black
CFM 1472 1401 1326 1251 1275 1198 1139 1085 1023
Heating Rise (
o
F) 45 48 50 53 52 56 59 62 65
Heating Rise (
o
C) 25 27 28 30 29 31 33 34 36
PGD4, PGS4, WPG4
