680ES OPERATOR MANUAL
25
© 2015 ICS®, Blount International Inc. Specications are subject to
change without notice. REV071315 F/N 577451
Operation
OPERATION
Never start the saw without the bar, chain and side cover properly assembled.
DO NOT operate the saw with loose, missing, damaged or improperly
installed or repaired parts.
Check that the components shown below are intact, undamaged, and installed
correctly:
• Side cover nuts torqued down properly
• Side cover not damaged and discharge port not plugged
• Handles not loose, gripping area is clean and undamaged
• Mud ap is not ripped, torn or missing and fully attached to the saw
• Cylinder cover is properly secured in place
• Muer not damaged and is adequately secured to cylinder
• Guidebar not bent or otherwise damaged such as rails dished and uneven
• Nose sprocket not excessively worn or broken, and turns freely
• Diamond chain does not have loose rivets, chassis damage, or missing
diamond segments
• Chain tensioner mechanism functions properly and pin is not bent or
broken
• Drive sprocket not excessively worn and slides easily on adapter
• Check alignment of drive sprocket and guidebar
Following are the basic instructions to assure safe operation of the saw.
WARNING
