iDataLink Maestro RR2 User Manual

ADS-RR(SI)-NIS01-DS-IG-EN maestro.idatalink.comAutomotive Data Solutions Inc. © 2019
4
NissaN FroNtier Nav aNd Bluetooth 2013-2019
VEHICLE WIRE REFERENCE CHART
Wire
Description
Connector
Name
Connector
Color
Connector
Type
Position Wire Color Polarity
Wire
Location
CanH A ~ 16 pin 06
Blue
(DATA) OBDII connector, under driver side dash
CanL A ~ 16 pin 14 Pink (DATA) OBDII connector, under driver side dash
SWI 1 B ~ 20 pin 16 White (DATA) Behind radio
SWI 2 B ~ 20 pin 06 Brown (DATA) Behind radio
SWI Feed B ~ 20 pin 15
Green
(-) Behind radio
