iDataLink Maestro RR2 - Page 9

ADS-RR(SI)-SUB01-DS-IG-EN maestro.idatalink.comAutomotive Data Solutions Inc. © 2019
3
Subaru ForeSter with NaV with SD CarD 2012-2013
65 87
1413 16
15
21
4
3
109 1211
1817 2019 2221 2423
6
10 11 12 13 14 15 16
1 2 3 4 5
6 7 8
9
E - LOCATED BEHIND RADIO
SWI 1
SWI 1
SWI FEED
SWI FEED
PURPLE/RED -
PURPLE/RED - SWI CIRCUIT 1 INPUT
BLACK/WHITE -
BLACK/WHITE - SWI GROUND FEED (-) OUTPUT
WIRES FROM
VEHICLE
WIRING DIAGRAM
STEP 2
OBDII CONNECTOR
LOCATED UNDER DRIVER SIDE DASH
NOTE: PIN SIDE VIEW. CONNECT TO TWISTED WIRES BEHIND CONNECTOR.
CANH
CANH
CANL
CANL
BROWN/RED - CANH
BROWN/YELLOW - CANL
STEP 1
MAESTRO RR MODULE
STEP 4
STEERING WHEEL
CONTROL CABLE
AUDIO
CABLE
NOT REQUIRED
DO NOT CONNECT
STEP 3
AFTERMARKET RADIO
YELLOW
BLACK
GRAY/RED
GRAY/YELLOW
RADIO BATTERY (+) WIRE
RADIO GROUND WIRE
RADIO ACCESSORY WIRE
RADIO VSS (IF EQUIPPED)
PIONEER RADIO: ENSURE THAT NOTHING IS PLUGGED IN W/R PORT.
