（1）先拧紧四个热床调平螺母后各松一圈，然后
在传送带平台上放上一张普通 A4 纸；
Tighten the four heat bed leveling nuts first
and then loosen one turn, and then put a
piece of ordinary A4 paper on the conveyor
belt platform;
螺母调节 Adjusting nut
（3）按下旋钮→Motion→Home Y,感受纸张的阻
力，通过按 Home Y 与调节 Y 轴限位开关使
得 A4 纸和喷嘴有轻微摩擦（Y 轴限位：阻力
太大，逆时针旋转；阻力太小，顺时针旋转）；
Press the knob→Motion→Home Y.Feel the
resistance of the paper, press Home Y and
adjust the Y-axis sensor switch to make the
A4 paper and the nozzle have a slight
resistance resistance.
（Y-Axis sensor: the resistance is too large,
rotate counterclockwise; resistance too
small, rotate clockwise);
感受纸张阻力 Feel paper resistance
（2）移动打印头到中间，使喷嘴轻微接触
A4 纸，有轻微阻力，然后调节 Y 轴限
位使得光电开关的灯刚好能亮；
Move the print head to the middle,
make the nozzle slightly touch the A4
paper with slight resistance, and then
adjust the Y-axis sensor so that the light
of the photoelectric switch can just be
bright;
调节 Y轴限位 Adjust Y-axis sensor
（4）按下旋钮→Motion→Auto home 归零，根
据纸张阻力大小，调节零点一侧的热床
平台螺母，使纸张有轻微阻力（热床螺
母：阻力大时，顺时针旋转；阻力小时，
逆时针旋转）；
Press the knob→Motion→Auto home
to reset to zero. Adjust the hot bed
platform nut on the zero side according
to the paper resistance.Make the
paper have a slight resistance.
(Hot bed nut: when the resistance is
large, rotate clockwise; when the
resistance is small, rotate
counterclockwise);
显示屏操作 Display operation
