The following are parts commonly required as replacements,
due to damage or expendability. The failure or absence is
likely to affect the safety and/or performance of this
appliance.
The list is extracted from the British Gas List of Parts which
contains all available spare parts.
The full list is held by British Gas, Caradon Plumbing Ltd.
distributors and merchants.
When ordering spares please quote:
1 Boiler model (see Data Plate)
2 Appliance G.C. number (see Data Plate)
3 Description
4 Quantity
5 Product No.
Key
No.
G.C. No Description No. Off/
Boiler
Product No.
1 173---148 Burner (mod. mini HE C24) 1 075427
173---149 Burner (mod. mini HE C28) 1 075535
2 Main heat exchanger + ’O’ rings (mod. mini HE C24) 1 173991
Main heat exchanger + ’O’ rings (mod. mini HE C28) 1 173992
3 Recuperator 1 173993
4 169---069 Injectors for natural gas (mod. mini HE C24) 12 075692
Injectors for natural gas (mod. mini HE C28) 14
E01---156 Injectors for LPG (mod. mini HE C24) 12 173982
Injectors for LPG (mod. mini HE C28) 14
5 H21---048 Fan (mod. mini HE C24) 1 173983
H21---049 Fan (mod. mini HE C28) 1 173984
6 E90---627 Gas valve + gaskets 1 172611
7 169---127 Air pressure switch (mod. mini HE C24) 1 173236
H08---605 Air pressure switch (mod. mini HE C28) 1 173136
8 E83---013 Safety valve 1 172494
9 Electronic regulation p.c.b. 1 174017
10 E83---142 Full sequence ignition device 1 172548
11 E00---684 Primary circuit flow switch 1 075419
12 E83---082 DHW flow switch (mod. mini HE C24) 1 172503
13 E00---688 Main. flow switch membrane 1 075421
14 E83---101 Overheat thermostat 1 172512
15 E57---048 DHW heat exchanger + ’O’ rings (mod. mini HE C24) 1 075460
E57---049 DHW heat exchanger + ’O’ rings (mod. mini HE C28) 1 075540
16 H20---986 Automatic air purger valve 1 173813
17 Pump + ’O’ rings 1 174004
18 E83---145 Temperature---pressure gauge 1 172551
19 H21---064 Flue thermostat 1 173985
20 E83---086 Three way diverter valve (electric actuator) 1 172505
21 H21---060 Sealed chamber gaskets kit 1 173986
22 E83---081 Magnetic flow switch and filter 1 172502
23 E83---127 Ignition electrode --- left 1 172533
24 E83---126 Ignition electrode --- right 1 172532
25 E83---122 Detection electrode 1 172531
26 E69---243 Window (glass + rubber frame) 1 170977
27 169---141 1/2” flat gasket 3 075514
28 169---033 3/4” flat gasket 4 075415
29 169---083 Fuse 1,6 A T 1 172562
30 164---026 Temperature probe (main or DHW circuit) 1 172496
31 H21---052 Side case panel 2 173987
