- 5 - - 6 -
Levels(61-085hasLEDindica-
tiononly).
• Auto-SwitchingVoltage/
ContinuityTechnology(61-086
only)
• Independentsolenoidandelec-
tronic circuitry design provides
back-up voltage indication for
added safety.
• LowImpedanceMeasuring
Device
• ReplaceableTestLeads
• Shieldedprobetips
• Ultrasonicallyweldedando-ring
sealed for added durability
Accessories:
• TL-82Resistor-fusedtestleads
• C-90Soft-sidedcarryingcase
To Measure AC Voltage:
• Ensurethattheplugforthetest
leads is fully seated into the
banana jacks.
• Connectthetesterinparallelwith
the load or circuit.
• Thetesterindicatesboththevolt-
age type and the voltage level.
(SeeTesterOperationtable)
To Measure DC Voltage:
• Ensurethattheplugforthetest
leads is fully seated into the
banana jacks.
• Connectthetesterinparallelwith
the load or circuit.
• Thetesterindicatesthevoltage
type, polarity, and the voltage level.
(SeeTesterOperationtable)
To Test for Continuity: (61-086
only)
• Ensurethattheplugforthetest
leads is fully seated into the
banana jacks.
• De-Energizecircuitbeforeperform-
ingcontinuitytest.Note,ifvoltage
is present in the circuit, the tester
automatically switches to voltage
indication mode.
• Testforcontinuitybyconnecting
the tester to the circuit.
• Ifcircuithas500kΩ or less
resistance, an audible indication
isheardandtheContinuityLED
lights.(SeeTesterOperation
table)
• Reversingprodsonthecircuit
under test verifies continuity ver-
suslowvoltage+DC.
Applications:
• LocatingBlownFuses
Withpoweroff:Placetesteracross
the suspected fuse to perform con-
