IDEAL 61-337

Electrical Specifications
Function Range
61-337
Resolution Accuracy
±(a%+b)
AC Voltage (V)
TRMS
400mV 0.1mV ±(1.5%+8)
4V 0.001V
±(1.3%+5)
40.00V 0.01V
400.0V 0.1V
600.0V 1V
AC Current (A)
TRMS
400.0μA 0.1μA
±(2%+5)
4000μA 1μA
40.00mA 0.01mA
400.0mA 0.1mA
4.000A 0.001A
±(2.5%+5)
10.00A 0.01A
DC Voltage (V)
400mV 0.1mV ±(1.5%+8)
4V 0.001V
±(1.3%+5)
40.00V 0.01V
400.0V 0.1V
600.0V 1V
DC Current (A)
400.0μA 0.1μA
±(2%+5)
4000μA 1μA
40.00mA 0.01mA
400.0mA 0.1mA
4.000A 0.001A
±(2.5%+5)
10.00A 0.01A
Resistance (Ω)
400.0Ω 0.1Ω
±(1.5%+5)
4.000kΩ 0.001kΩ
40.00kΩ 0.01kΩ
400.0kΩ 0.1kΩ
4.000MΩ 0.001MΩ
±(2%+5)
40.00MΩ 0.01MΩ
25
Function Range
61-337
Resolution Accuracy
±(a%+b)
Capacitance
400.0nF 0.1nF
±(5%+15)
4.000uF 0.001uF
40.00uF 0.01uF
400.0uF 0.1uF
4000uF 1uF ±10%
Frequency Hz 9.999Hz ~ 9.999KHz 0.001Hz ~ 0.1KHz ±(0.5%+5)
Duty Cycle % 0.1%~99.9% 0.1%
Temp. °F -40~1832°F 1°F
±(2.0%+7)@-40~32°F
±(2.0%+6)@33~1832°F
Temp. °C -40~1000°C 1°C
±(2.0%+4)@-40~0°C
±(2.0%+3)@1~1000°C
Continuity 0.1 Ω
≤10Ω : Buzzer beeps
and red indicator LED
illuminates continuously
≥70Ω : No buzzer beep
Diode test 0.001V
Silicon PN joint with
forward voltage about
0.5V to 0.8V
NCV 40-600V
≥40V/(50~60Hz), with direct wire contact, red
indicator LED flashes at a frequency of 3Hz
, and the buzzer beeps at a frequency of 3Hz
simultanously
1. Overload Protection: 600VRMS MAX Fuses FF 0.4A 600V and F 10 A 600V
2. Accuracy a is % of reading and b is LSD (Least Significant Digit).
