IDEAL 61-357

Electrical Specifications
Function Range
61-347 & 61-357
Resolution Accuracy
±(a%+b)
AC Voltage (V)
TRMS
(61-357 has LoZ)
600mV 0.1mV ±(1.5%+8)
6V 0.001V
±(1.3%+5)60.00V 0.01V
600.0V 0.1V
1000V 1V ±(1.5%+5)
AC Current (A)
TRMS
600.0μA 0.1μA
±(2%+5)
6000μA 1μA
60.00mA 0.01mA
600.0mA 0.1mA
6.000A 0.001A
±(2.5%+5)
10.00A 0.01A
DC Voltage (V)
600mV 0.1mV ±(1.5%+8)
6V 0.001V
±(1.3%+5)60.00V 0.01V
600.0V 0.1V
1000V 1V ±(1.5%+5)
DC Current (A)
600.0μA 0.1μA
±(2%+5)
6000μA 1μA
60.00mA 0.01mA
600.0mA 0.1mA
6.000A 0.001A
±(2.5%+5)
10.00A 0.01A
Resistance (Ω)
600.0Ω 0.1Ω
±(1.5%+5)6.000kΩ 0.001kΩ
60.00kΩ 0.01kΩ
600.0kΩ 0.1kΩ
±(2%+5)6.000MΩ 0.001MΩ
60.00MΩ 0.01MΩ
25
Function Range
61-347 & 61-357
Resolution Accuracy
±(a%+b)
Capacitance
600.0nF 0.1nF
±(5%+15)
6.000uF 0.001uF
60.00uF 0.01uF
600.0uF 0.1uF
6000uF 1uF ±10%
Frequency Hz 9.999Hz ~ 9.999KHz
0.001Hz ~
0.1KHz
±(0.5%+5)
Duty Cycle % 0.1%~99.9% 0.1%
Temp. °F -40~1832°F 1°F
±(2.0%+7)@-40~32°F
±(2.0%+6)@33~1832°F
Temp. °C -40~1000°C 1°C
±(2.0%+4)@-40~0°C
±(2.0%+3)@1~1000°C
Continuity 0.1 Ω
≤10Ω : Buzzer beeps
and red indicator LED
illuminates continuously
≥70Ω : No buzzer beep
Diode test 0.001V
Silicon PN joint with
forward voltage about
0.5V to 0.8V
NCV 40-600V
≥40V/(50~60Hz), with direct wire contact,
red indicator LED flashes at a frequency of
3Hz , and the buzzer beeps at a frequency
of 3Hz simultanously
1. Overload Protection: 1000VRMS MAX Fuses FF 0.6A 1000V and FF 11A 1000V
2. Accuracy a is % of reading and b is LSD (Least Significant Digit).
