Environmental Specifications
Operating Temperature:
32ºF to 86ºF (0ºC to 30ºC) (80%RH)
86ºF to 140ºF (30ºC to 40ºC) (75%RH)
104ºF to 122ºF (40ºC to 50ºC) (45%RH)
Operating Altitude:
< 6500 ft (< 2000 m)
Storage Temperature:
14ºF to 140ºF (-10ºC to 60ºC) (<80%RH)
Mechanical Specifications
Dimensions (L x W x H): 7.83 in. x 3.74 in. x 2.24 in.
(199 mm. x 95 mm. x 57 mm.)
Weight: 1.147 LBS (0.52 KG)
Display: LCD
Display Count: 6000
Power Source: 3 x 1.5V AAA
Battery Life: 100 Hours Typical
Ingress Protection Rating: IP52 dust and water resistant
EMC/EMI
26
CISPR 22 3rd Edition. Class B Limits.
EN 55032
CISPR 32
CISPR 11
FCC 15. 107 with reference to Section 15.109 (g).
ICES-003
EN 61326-2-2 Sec 6.4.2.101
Intended for indoor use
