Quick Reference Boiler Piping and Wiring Guide
The condensate produced by gas-red
condensing boilers, furnaces and tankless
heaters is acidic and has the potential
to harm the environment and the sewer
system. The Condensate Neutralizer Pump
from PurePro is ideal for installations that
require both condensate removal and
neutralization.
Features and benets:
• 1.9 Gal./hr.*
• 500,000 BTU
• 20 ft. lift, high performance pump
• Comes with high level oat for hook
up to alarm system
• Condensate Neutralizer Pump
prevents acidic condensate from
corroding drains and sewer
systems
• Neutralized condensate is more
environmentally friendly
• Low prole design for appliances
with near oor condensate drain
• All materials made from corrosion
resistant material
• 1 gallon tank with baes designed
to channel ow through media for
complete neutralization
• Additional inlet for A/C condensate
• High level alarm contacts
• Includes initial charge of
Neutralizing Media
• Can be wall mounted
APPENDIX
PUREPRO CONDENSATE NEUTRALIZER PUMP
*Check with the appliance manufacturer for
condensate. As a guideline 500,000 BTU/hr. at 93%
eciency will produce approximately 1.9 Gal./hr.
Specications
The condensate neutralization tank with pump shall be PurePro model PROPP-PUMP.
System shall include 1 gallon tank and lid made from SAN, pump with thermal cut-out
and electrically and electrically certied to CAN/CSA STD C22.2 no. 108 conforms to
ANSI/UL STD 778; low level oat switch; high level oat switch for remote alarm system;
check valve; 20 feet of 1/2" vinyl tubing, 3/4" FNPT inlet connection; 6 feet long power
cord. Power supply: 110/60/0.6A. Comes with 2.7 lbs. of neutralization media.
Weight 8.5 lbs. (full)
Electrical
Pump: 120VAC 60Hz, 87W, 0.89 Amps
High level safety switch rating: 125 or 250VAC 6A, 125V DC 0.4A, 250V DC 0.3A
Pump Performance
Submerged pump is self-priming, 74 gph @ free ow, 32 gph @ 20 ft.
CONDENSATE NEUTRALIZER PUMP
Webb# Mfr# Description
681739 PROPPPUMP Condensate Neutralization Tank with Pump – 500K BTU
681740 PROPPPUMPRK Replacement Neutralization Media for PROPP-PUMP
689667 PRORPUMP Replacement Pump
696879 PROPP3.5GAL Condensate Neutralizer Media 3.5 Gallon Bucket
Pump is certied to CAN/CSA STD C22.2 no. 108
4007096 Pump conforms to ANSI/UL STD 778
