- Installation & Servicing
INSTALLATION
43
INFORMATION MODE (with code)
44
COMMUNICATION MODE (with code)
Press Display Description
C O N N
In this mode the communication between the boiler control module, optional control interface
kit, and optional programmable room thermostat or modulating sequencer is shown.
No communication
There is only communication between the boiler control module and optional controls interface
kit.
There is communication between all devices.
FLASHING
FLASHING
I N F O
Actual Flow Temperature T1 ºC
1. 2 1
FLASHING
Actual Return Temperature T2 ºC
2. 2 1
3. - 3 7
Outside Temperature T4 ºC
(-37 displayed if outside sensor kit not fitted)
4. - 3 7
DHW Temperature T3 ºC
(-37 displayed if tank sensor kit not fitted)
N/A
5. - 3 7
Press Display Description
Set Flow Temperature ºC
6. 8 2
7. 0 0
Rate of Return Temperature Rise ºC/s
8. 0 0
Rate of Flow Temperature Rise ºC/s
9. 0 0
N/A
A. - 3 6
Rate of DHW Temperature Rise ºC/s
INSTALLATION
To Next Page
