Page 7
Operation 61-946
1. Magnetic Hanging Strap Clip
2. Test Lead Terminals
3. LED Indicators
4. On/Off Button
5. Support Kickstand
6. Battery Cover
7. Main Display (LCD)
8. Sensitivity Level Select
9. Mute Button
10. Back-light Button
11. On/Off Button
12. Protective Rubber Overmolding
1
2
3
4 5
6
7
8
9
10
11
12
