INsTALLATION
vogue combination boiler - Installation and Servicing
9 FRONT pANEL REMOVAL
1. Loosen the 2 screws retaining the front panel at the
bottom.
2. Release catches at rear of door by pulling
downwards.
3. Pull the underside front panel forward then lift
upwards to remove.
pack B Contents Telescopic
A Telescopic Flue Terminal
B Flue Turret
C Rubber Terminal Wall Seal
D Screw
E Sealing Tape
F Wall Seal (White)
D
C
A
E
F
B
1
pack B Contents Non-Telescopic
A Flue Terminal
B Flue Turret
C Rubber Terminal Wall Seal
D Cutting Aid
E Wall Seal (White)
A
D
B
CE
8 UNpACKINg CONT’D
2
INsTALLATION
