Note.
A at or pitched roof ashing plate (not supplied) is required before proceeding
with the installation of this kit.
This kit is suitable for both at and pitched roof terminations, using a concentric
ue to run vertically from the top of the boiler and terminating above roof level.
Connection to the top of the boiler is made using a separately supplied
vertical connector.
WEAThER pROOFINg
Where the ue passes through the roof line an adequate seal
must be made. This is achieved by using either:
- Flat roof weather collar
or
- Universal weather collar.
ACCEssORIEs
Flue Duct Extension Kits are available for ue
lengths extending beyond 1m. These packs
contain 1m extension ducts and may be cut to
the desired length.
If the offset vertical option is used an elbow
Kit is required. For a full accessories list
refer to page 7 , Optional Extras and Frame
21, Flue Arrangement.
