Battery Replacement (61-076):
• Replace batteries when touching the leads
together no longer lights the continuity LED.
• Remove test leads from tester.
• Carefully, pry the two battery caps from the
bottom of the case using a screwdriver.
• Replace the batteries.
• Snap the battery caps back in place ensuring
the cap is flush with the bottom of the case.
Accessories:
• 61-070 Standard test leads
• 61-072 Resistor-fused test leads
• C-90 Soft-sided carrying case
• 61-010 Leather case
Maintenance:
• Clean the case with a damp cloth and mild
detergent. Do not use abrasives or solvents.
Service, and Replacement Parts:
For replacement parts or to inquire about service
information contact Technical Support:
1-877-201-9005 or visit our website
www.testersandmeters.com.
Warranty Statement:
This tester is warranted to the original purchaser against
defects in material and workmanship for two years from
the date of purchase. During this warranty period, IDEAL
INDUSTRIES, INC. will, at its option, replace or repair
the defective unit, subject to verification of the defect or
malfunction.
This warranty does not cover fuses, batteries or damage
from abuse, neglect, accident, unauthorized repair, alter-
ation, or unreasonable use of the instrument.
Any implied warranties arising out of the sale of an
IDEAL product, including but not limited to implied war-
ranties of merchantability and fitness for a particular pur-
pose, are limited to the above. The manufacturer shall
not be liable for loss of use of the instrument or other
incidental or consequential damages, expenses, or eco-
nomic loss, or for any claim or claims for such damage,
expenses or economic loss.
State laws vary, so the above limitations or exclusions
may not apply to you. This warranty gives you specific
legal rights, and you may also have other rights which
vary from state to state.
6
5
Specifications:
VAC Ranges: 120V, 240V, 480V, 600V AC.
VDC Ranges: 120V, 240V, 600V DC
Volts Accuracy: Relative indication only
Continuity: LED lights at <500kΩ
Response time of 100ms.
Frequency: Operates at 25-60 Hz
Overload 1000VDC/750VAC rms.
protection:
Operating 32°F to 122°F
Environment: (0 to 50°C)(<70% humidity)
Storage Temp.: -4°F to 140°F (-20 to 60°C)
(<80% humidity)
Battery: (4) 1.5V (61-201, IEC LR44)
Battery Life: 200 hours typical.
Accessories Test Leads, (4) Batteries,
included: Operating Manual
Dimensions: 7.2"H x 2.4"W x 1.5"D
[183H x 61W x 38D]mm
Weight: 8.0 oz (227g)
Safety: UL-61010, CAT III-600V
Double Insulation
Instrument has been evaluated and complies
with insulation category III (overvoltage
category III). Pollution degree 2 in accordance
with IEC-644. Indoor use.
