6: ALLOCATION NUMBERS
« FC4A MICROSMART USER’S MANUAL » 6-9
M8100 Data Link Slave Station 17 Communication Completion Relay Operating Cleared
M8101 Data Link Slave Station 18 Communication Completion Relay Operating Cleared
M8102 Data Link Slave Station 19 Communication Completion Relay Operating Cleared
M8103 Data Link Slave Station 20 Communication Completion Relay Operating Cleared
M8104 Data Link Slave Station 21 Communication Completion Relay Operating Cleared
M8105 Data Link Slave Station 22 Communication Completion Relay Operating Cleared
M8106 Data Link Slave Station 23 Communication Completion Relay Operating Cleared
M8107 Data Link Slave Station 24 Communication Completion Relay Operating Cleared
M8110 Data Link Slave Station 25 Communication Completion Relay Operating Cleared
M8111 Data Link Slave Station 26 Communication Completion Relay Operating Cleared
M8112 Data Link Slave Station 27 Communication Completion Relay Operating Cleared
M8113 Data Link Slave Station 28 Communication Completion Relay Operating Cleared
M8114 Data Link Slave Station 29 Communication Completion Relay Operating Cleared
M8115 Data Link Slave Station 30 Communication Completion Relay Operating Cleared
M8116 Data Link Slave Station 31 Communication Completion Relay Operating Cleared
M8117 Data Link All Slave Station Communication Completion Relay Operating Cleared
M8120 Initialize Pulse Cleared Cleared
M8121 1-sec Clock Operating Cleared
M8122 100-ms Clock Operating Cleared
M8123 10-ms Clock Operating Cleared
M8124 Timer/Counter Preset Value Changed Maintained Maintained
M8125 In-operation Output Cleared Cleared
M8126-M8127 — Reserved — — —
M8130 High-speed Counter 1 (I0-I2) Reset Status Maintained Cleared
M8131
High-speed Counter 1 (I0-I2) Current Value Over flow (two-phase)
High-speed Counter 1 (I0-I2) Comparison ON Status (single-phase)
Maintained Cleared
M8132 High-speed Counter 1 (I0-I2) Current Value Under flow Maintained Cleared
M8133 High-speed Counter 2 (I3) Comparison ON Status Maintained Cleared
M8134 High-speed Counter 3 (I4) Comparison ON Status Maintained Cleared
M8135 High-speed Counter 4 (I5-I7) Reset Status Maintained Cleared
M8136
High-speed Counter 4 (I5-I7) Current Value Over flow (two-phase)
High-speed Counter 4 (I5-I7) Comparison ON Status (single-phase)
Maintained Cleared
M8137 High-speed Counter 4 (I5-I7) Current Value Under flow Maintained Cleared
M8140 Interrupt Input I2 Status Cleared Cleared
M8141 Interrupt Input I3 Status Cleared Cleared
M8142 Interrupt Input I4 Status Cleared Cleared
M8143 Interrupt Input I5 Status Cleared Cleared
M8144 Timer Interrupt Status Cleared Cleared
M8145-M8147 — Reserved — — —
M8150 Comparison Result Greater Than Maintained Cleared
M8151 Comparison Result Less Than Maintained Cleared
M8152 Comparison Result Equal To Maintained Cleared
M8153 — Reserved — — —
M8154 Catch Input I2 ON/OFF Status Maintained Cleared
M8155 Catch Input I3 ON/OFF Status Maintained Cleared
M8156 Catch Input I4 ON/OFF Status Maintained Cleared
M8157 Catch Input I5 ON/OFF Status Maintained Cleared
Allocation
Number
Description CPU Stopped Power OFF
To Next Page
