6: ALLOCATION NUMBERS
6-16 « FC4A MICROSMART USER’S MANUAL »
Special Data Registers for Port 2
Note: D8100 through D8199 are not available on the all-in-one 10-I/O type CPU module; all other CPU modules have D8100
through D8199.
D8000 System Setup ID (Quantity of Inputs)
The total of input points provided on the CPU module and connected expansion input modules is stored to D8000. When a
mixed I/O module (4 inputs and 4 outputs) is connected, 8 input points are added to the total.
D8001 System Setup ID (Quantity of Outputs)
The total of output points provided on the CPU module and connected expansion output modules is stored to D8001.
When a mixed I/O module (4 inputs and 4 outputs) is connected, 8 output points are added to the total.
Allocation
Number
Description Updated See Page
D8085 Slave Station 17 Communication Error (at Master Station) When error occurred 25-4
D8086 Slave Station 18 Communication Error (at Master Station) When error occurred 25-4
D8087 Slave Station 19 Communication Error (at Master Station) When error occurred 25-4
D8088 Slave Station 20 Communication Error (at Master Station) When error occurred 25-4
D8089 Slave Station 21 Communication Error (at Master Station) When error occurred 25-4
D8090 Slave Station 22 Communication Error (at Master Station) When error occurred 25-4
D8091 Slave Station 23 Communication Error (at Master Station) When error occurred 25-4
D8092 Slave Station 24 Communication Error (at Master Station) When error occurred 25-4
D8093 Slave Station 25 Communication Error (at Master Station) When error occurred 25-4
D8094 Slave Station 26 Communication Error (at Master Station) When error occurred 25-4
D8095 Slave Station 27 Communication Error (at Master Station) When error occurred 25-4
D8096 Slave Station 28 Communication Error (at Master Station) When error occurred 25-4
D8097 Slave Station 29 Communication Error (at Master Station) When error occurred 25-4
D8098 Slave Station 30 Communication Error (at Master Station) When error occurred 25-4
D8099 Slave Station 31 Communication Error (at Master Station) When error occurred 25-4
D8100-D8102 — Reser ved — — —
D8103 On-line Mode Protocol Selection When sending/receiving data 27-3
D8104 RS232C Control Signal Status Every scan 17-29
D8105 RS232C DSR Input Control Signal Option When sending/receiving data 17-30
D8106 RS232C DTR Output Control Signal Option When sending/receiving data 17-30
D8107-D8108 — Reser ved — — —
D8109 Retry Cycles At retry 27-3
D8110 Retry Interval Every scan during retry 27-3
D8111 Modem Mode Status At status transition 27-3
D8112-D8114 — Reser ved — — —
D8115-D8129 AT Command Result Code When returning result code 27-3
D8130-D8144 AT Command String When sending AT command 27-3
D8145-D8169 Initialization String When sending init. string 27-3
D8170-D8199 Telephone Number When dialing 27-3
