24: ANALOG I/O CONTROL
24-12 « FC4A MICROSMART USER’S MANUAL »
Optional Range
When Optional range is selected as an analog input data type, the analog input is linearly converted into digital data in the
range between the minimum and maximum values designated in the Configure Parameters dialog box.
Celsius and Fahrenheit
When Celsius or Fahrenheit is selected as an analog input data type, the analog input data range depends on the analog
input signal type, scale value, and the type of the analog input module, FC4A-L03AP1, FC4A-J4CN1, and FC4A-J8AT1.
•
FC4A-L03AP1
• FC4A-J4CN1
• FC4A-J8AT1
Resistance
When Resistance is selected as an analog input data type, the analog input is linearly converted into digital data in the
range described in the table below. This option is available only when NTC or PTC type thermistor is selected for the
FC4A-J8AT1.
•
FC4A-J8AT1
Type No. FC4A-L03A1 FC4A-L03AP1 FC4A-J2A1 FC4A-J4CN1 FC4A-J8C1 FC4A-J8AT1
Analog Input Data Analog input data minimum value to maximum value (–32768 to 32767)
Analog Input Signal Type
Celsius Fahrenheit
Temperature (°C) Analog Input Data Temperature (°F) Analog Input Data
Type K thermocouple 0 to 1300 0 to 13000 32 to 2372 320 to 23720
Type J thermocouple 0 to 1200 0 to 12000 32 to 2192 320 to 21920
Type T thermocouple 0 to 400 0 to 4000 32 to 752 320 to 7520
Pt100 resistance thermometer –100.0 to 500.0 –1000 to 5000 –148.0 to 932.0 –1480 to 9320
Analog Input
Signal Type
Scale
Celsius Fahrenheit
Temperature (°C) Analog Input Data Temperature (°F) Analog Input Data
Type K thermocouple
×10 to 1300 0 to 1300 32 to 2372 32 to 2372
×10 0.0 to 1300.0 0 to 13000 32.0 to 2372.0 320 to 23720
Type J thermocouple
×10 to 1200 0 to 1200 32 to 2192 32 to 2192
×10 0.0 to 1200.0 0 to 12000 32.0 to 2192.0 320 to 21920
Type T thermocouple
×10 to 400 0 to 400 32 to 752 32 to 752
×10 0.0 to 400.0 0 to 4000 32.0 to 752.0 320 to 7520
Pt100, Pt1000
resistance
thermometer
×1 –100 to 500 –100 to 500 –148 to 932 –148 to 932
×10 –100.0 to 500.0 –1000 to 5000 –148.0 to 932.0 –1480 to 9320
×100
0.00 to 500.00
–100.00 to 327.67
0 to 50000
–10000 to 32767
0.00 to 655.35
–148.00 to 327.67
0 to 65535
–14800 to 32767
Ni100, Ni1000
resistance
thermometer
×1 –60 to 180 –60 to 180 –76 to 356 –76 to 356
×10 –60.0 to 180.0 –600 to 1800 –76.0 to 356.0 –760 to 3560
×100 –60.00 to 180.00 –6000 to 18000
0.00 to 356.00
–76.00 to 327.67
0 to 35600
–7600 to 32767
Analog Input
Signal Type
Scale
Celsius Fahrenheit
Temperature (°C) Analog Input Data Temperature (°F) Analog Input Data
NTC thermistor
×1 –50 to 150 –50 to 150 –58 to 302 –58 to 302
×10 –50.0 to 150.0 –500 to 1500 –58.0 to 302.0 –580 to 3020
Analog Input Signal Type
Resistance
Resistance (Ω) Analog Input Data
NTC/PTC thermistor 0 to 100000 0 to 10000
