« FC4A MICROSMART USER’S MANUAL » vii
INDEX
LRET 18-3
M maintain outputs while CPU stopped M8025 6-11
maintaining catch input 5-19
maintenance protocol 26-2
manipulated variable 21-13
master
control instruction
7-23
station 25-7
maximum
AS-Interface bus cycle time
28-5
communication distance 1-8
relay outputs turning on simultaneously 2-31
MCS and MCR instructions 7-23
memory
backup error run/stop selection
5-3
cartridge 2-5, 2-15, 2-64
information D8003 6-17
mixed I/O module 2-39, 30-8
specifications 2-40
terminal arrangement 2-41
Modbus
ASCII
17-36
RTU 17-36
mode 5-11, 5-12, 15-1
modem
cable 1C
27-1, 30-4
mode 27-1
status 27-3
status data register 27-7
protocol 27-10
module
HMI base
4-1, 4-2
RS232C communication 4-1
RS485 communication 4-2
specifications 2-1
monitor
AS-Interface slave
28-33
operation 4-8
monitoring
digital I/O and changing output status
28-12
PLC status 26-3
WindLDR 29-1
mounting
clip
3-1
direction 3-12
hole layout
for direct mounting
3-8
RS232C/RS485 converter 26-5
on DIN rail 3-7
on panel surface 3-7
position communication block 28-36
strip 3-7
MOV 9-1
move 9-1
move not 9-4
MOVN 9-4
MUL 11-1
multiple
OUT and OUTN
7-2
usage of MCS instructions 7-24
multiplication 11-1
N no operation 8-7
NOP 8-7
normal
operating conditions
2-3, 2-13
protected
data exchange off
28-15
mode 28-15
offline 28-15
Normal_Operation_Active 28-24
O O/I communication cable
1C
30-5
2C 30-6
ODI 28-20
Off-line 28-24
Offline_Ready 28-24
on-line mode protocol selection 27-3
opcode 8-5
operand
allocation numbers
6-1, 6-3
for analog I/O modules 6-5
for data link master station 6-6
for data link slave station 6-6
areas discontinuity 8-6
AS-Interface 28-18
expansion I/O module 6-18
operating
procedure
data link system
25-11
modem mode 27-11
range input 2-6, 2-16, 2-24, 2-25, 2-40
status
analog I/O
24-3
during errors 29-4
operation
basics
4-1, 28-6
mode 28-15
operational state 27-2
operator interface communication system 1-7
optional cartridge information D8031 6-17
OR and ORN instructions 7-4
OR LOD instruction 7-5
OR word 12-1
originate mode 27-2, 27-3
ORW 12-1
others tab 2-65, 5-24, 5-25, 15-7
OUT and OUTN
instructions
7-2
multiple 7-2
output
data
28-35, 28-36
delay 2-7, 2-18, 2-31, 2-41
during errors 29-4
internal circuit 2-17, 2-33, 2-36
LEDs 28-16
module 2-30, 30-7
points 16-1, 16-3
wiring 3-14
overflow 6-12, 6-13
overlapping coordinates 19-6
P parameter 28-4
image (PI) 28-27
