2: M
ODULE
S
PECIFICATIONS
« FC4A M
ICRO
S
MART
U
SER
’
S
M
ANUAL
»
2-29
AC Input Module T
er
minal Arrangement and Wiring Diagrams
FC4A-N08A11 (8-point AC Input Module) — Screw T
er
minal Type
Applicable
T
erminal Block:
FC4A-PMT11P (supplied with the input module)
7
COM1
0
1
2
3
4
5
6
7
AC.IN
1
02
3
COM0
NC
4
5
6
Te
r
minal No.
Output
0I
0
1I
1
2I
2
3I
3
COM0
COM0
NC
NC
4I
4
5I
5
6I
6
7I
7
COM1
COM1
AC
AC
•
Tw
o COM terminals are
not
connected together internally
.
•
For input wiring precautions, see page 3-13.
•
Do not connect an external load to the input terminals.
48
50
