Mixed I/O Modules
Analog I/O Modules
AS-Interface Master Module
Optional Modules, Adapters, and Cartridges
Note *: RS232C or RS485 communication adapters can also be installed on the HMI base module mounted next to the slim
type CPU module.
Input Type Output Type I/O Points Terminal Type No.
24V DC Sink/Source
Relay Output
240V AC/30V DC, 2A
8 (4 in / 4 out) Removable Terminal Block FC4A-M08BR1
24 (16 in / 8 out) Non-removable Terminal Block FC4A-M24BR2
Name I/O Signal I/O Points Category Terminal Type No.
Analog I/O Module
Voltage (0 to 10V DC)
Current (4 to 20mA)
2 inputs
END
Refresh
Type
Removable
Ter minal
Block
FC4A-L03A1
Voltage (0 to 10V DC)
Current (4 to 20mA)
1 output
Thermocouple (K, J, T)
Resistance thermometer (Pt100)
2 inputs
FC4A-L03AP1
Voltage (0 to 10V DC)
Current (4 to 20mA)
1 output
Analog Input Module
Voltage (0 to 10V DC)
Current (4 to 20mA)
2 inputs FC4A-J2A1
Voltage (0 to 10V DC)
Current (4 to 20mA)
Thermocouple (K, J, T)
Resistance thermometer
(Pt100, Pt1000, Ni100, Ni1000)
4 inputs
Ladder
Refresh
Type
FC4A-J4CN1
Voltage (0 to 10V DC)
Current (4 to 20mA)
8 inputs FC4A-J8C1
Thermistor (PTC, NTC) 8 inputs FC4A-J8AT1
Analog Output Module
Voltage (0 to 10V DC)
Current (4 to 20mA)
1 output
END
Refresh
FC4A-K1A1
Voltage (–10 to +10V DC)
Current (4 to 20mA)
2 outputs
Ladder
Refresh
FC4A-K2C1
Name Terminal Type No.
AS-Interface Master Module Removable Terminal Block FC4A-AS62M
Name Description Type No.
HMI Module For displaying and changing required operands FC4A-PH1
HMI Base Module For mounting HMI module with slim type CPU module FC4A-HPH1
RS232C Communication Adapter Mini DIN connector type for all-in-one 16- and 24-I/O CPU modules * FC4A-PC1
RS485 Communication Adapter
Mini DIN connector type for all-in-one 16- and 24-I/O CPU modules * FC4A-PC2
Ter minal block type for all-in-one 16- and 24-I/O CPU modules * FC4A-PC3
RS232C Communication Module Mini DIN connector type for slim type CPU module FC4A-HPC1
RS485 Communication Module
Mini DIN connector type for slim type CPU module FC4A-HPC2
Ter minal block type for slim type CPU module FC4A-HPC3
Memory Cartridge
32KB EEPROM for storing a user program FC4A-PM32
64KB EEPROM for storing a user program FC4A-PM64
Clock Cartridge Real time calendar/clock function FC4A-PT1
