IDEC FC4A-C24R2 User Manual

APPENDIX
« FC4A MICROSMART USER’S MANUAL » A-9
Accessories
BX Series I/O Terminals and Applicable Cables
Specify required designation codes in place of ➀, ➁, and ➂.
Name Function Type No.
RS232C/RS485 Converter
Used for interface between a computer and the MicroSmart CPU
modules in the computer link 1:N communication system or
through modems
FC2A-MD1
RS232C Cable (4-wire)
(1.5m/4.92 ft. long)
Used to connect the RS232C/RS485 converter to a computer,
with D-sub 9-pin female connector to connect to computer
HD9Z-C52
DIN Rails
(1m/3.28 ft. long)
35-mm-wide aluminum DIN rail to mount MicroSmart modules
(package quantity 10)
BAA1000PN10
DIN Rails
(1m/3.28 ft. long)
35-mm-wide steel DIN rail to mount MicroSmart modules
(package quantity 10)
BAP1000PN10
End Clips
Used on DIN rail to fasten MicroSmart modules
(package quantity 10)
BNL6PN10
Direct Mounting Strips
Used for direct mounting of slim type CPU or I/O modules on a
panel (package quantity 5)
FC4A-PSP1PN05
10-position Terminal Blocks For I/O modules (package quantity 2) FC4A-PMT10PN02
11-position Terminal Blocks For I/O modules (package quantity 2) FC4A-PMT11PN02
13-position Terminal Blocks
For slim type CPU modules FC4A-D20RK1 and FC4A-D20RS1
(package quantity 2)
FC4A-PMT13PN02
16-position Terminal Blocks For slim type CPU module FC4A-D20RK1 (package quantity 2) FC4A-PMTK16PN02
16-position Terminal Blocks For slim type CPU module FC4A-D20RS1 (package quantity 2) FC4A-PMTS16PN02
20-position Connector Socket MIL connector for I/O modules (package quantity 2) FC4A-PMC20PN02
26-position Connector Socket MIL connector for slim type CPU modules (package quantity 2) FC4A-PMC26PN02
Phoenix Ferrule Ferrule for connecting 1 or 2 wires to screw terminal See page 3-18
Phoenix Crimping Tool Used for crimping ferrules See page 3-18
Phoenix Screwdriver Used for tightening screw terminals See page 3-18
WindLDR Programming and monitoring software for Windows PC (CD) FC9Y-LP2CDW
MicroSmart User’s Manual This printed manual FC9Y-B812
MicroSmart
Cable Type No. I/O Terminal Type No. Connector
Module Type No.
CPU Module
FC4A-D20K3
FC4A-D20S3
FC4A-D40K3
FC4A-D40S3
FC9Z-H➀➁26
BX1D-➂26A
BX1F-➂26A
26-pole MIL connector
Input Module
FC4A-N16B3
FC4A-N32B3
FC9Z-H➀➁20
BX1D-➂20A
BX1F-➂20A
BX7D-BT16A1T (16-pt relay output)
20-pole MIL connector
Output Module
FC4A-T16K3
FC4A-T16S3
FC4A-T32K3
FC4A-T32S3
➀ Cable Length Code ➁ Cable Shield Code ➂ Terminal Screw Style Code
050: 0.5m
100: 1m
200: 2m
300: 3m
A: Shielded cable
B: Non-shielded cable
T: Touch-down terminal
S: Screw terminal
