Connect a power cable and SATA cable to each hard drive. The SATA cables should be connected as shown below.
• Changing the master/slave jumper settings is not necessary for SATA hard drives.
• The front and rear of the mounting guide are not identical. When installing the hard drive to the mounting guide,
make sure that the connectors on the hard drive are not interrupted.
6
Close the top cover and secure it using screws.
