IDS Opera Duo User Manual

IDS Ingegneria Dei Sistemi S.p.A.
N doc:MN/2014/024 - Rev. 1.0
OPERA DUO v. 1.0 – User Manual
26 / 34
All information contained in this document is property of IDS. All rights reserved
4. ASSEMBLY PROCEDURE
The procedure to assemble the Opera Duo is very simple and can be performed by one
person.
To assemble the system follow these steps:
1. Unfold the radar main body (paragraph 4.1);
2. Connect the laptop (paragraph 4.2);
3. Insert the battery (paragraph 4.3);
4. Mount the Spray support (optional, paragraph 4.4);
5. Mount the GPS support (optional, paragraph 4.5).
4.1 Unfold the radar main body
To unfold the Opera Duo main body place it to on the ground, press the central handle
button and raise the rudder to the desired angle (Fig. 4.1).
Fig. 4.1 – Unfold the Opera Duo
