Innovative DisplayWorks

G-10f/GCG-10f

CONDENSER MAINTENANCE

It is essential to keep the condenser coils clean and free of dust and debris at all

times.Itisrequiredtoperiodicallycleanthecondensercoilswithasoftbristlebrush

or vacuum-cleaner to properly maintain the refrigeration system. Failure to clean

the condenser at regular intervals may cause failure of the refrigeration system and

couldvoidthewarranty.

1 Remove the rubber cap from the front grill.

2UsingaPhillipsscrewdriver,removethethreescrewsas

shown.

3Thefrontplasticgrillcannowberemovedbypullingitup.

4Usingplasticbristlebrush,carefullycleanthecoilbeingawarethatnscanbendorbe

damagediftoomuchforceisused-shownleft.

5ReplacegrillandutilizethePhillipsscrewdrivertotightenthescrewsintoplace,replacetherubbercaps.

MAINTENANCE - Cleaning Shutdown Questions and Answers

Cleaning and Maintenance

1 Unplug the cooler before cleaning.

2 Useasoftclothorspongewithwaterorsoap(non-corrosivemilddetergent),whilecleaning.

 Aftercleaning,wipethecoolerusingdryclothtokeepthecoolerfromrusting.

3 Donotspraywateronthecooler,anddonotusehardorsteelbrushestocleanthecooler.

4 Donotuseorganicsolvents,boilingwater,washingpowderoracidwhilecleaning.

5. Adrainorwasteoutletmaybeprovidedforthedrainingofadisplayrefrigerator.Ifthedisplay

refrigeratordrainsareprovidedforushing,theyshallhaveaminimuminternaldiameterof1˝(25mm).

Ifthecooler’spowerwillbeoffforalongperiodoftime,unplugit,cleanasinstructedabove,andkeepdoor

open until dry.

IDW G-10-F33EB-HC User Manual

Questions and Answers:
