IMB-9454G Motherboard
A.1 BIOS Configuration Options
Below is a list of BIOS configuration options described in Chapter 5.
System Overview ...................................................................................................94
ATA/IDE Configuration [Compatible]...................................................................98
Legacy IDE Channels [SATA Pri, PATA Sec]......................................................99
IDE Master and IDE Slave .....................................................................................99
Auto-Detected Drive Parameters....................................................................... 100
Type [Auto] ................................................................................................. 101
ZIP ................................................................................................. 101
LS-120 ................................................................................................. 101
LBA/Large Mode [Auto]...................................................................................... 101
Block (Multi Sector Transfer) [Auto]................................................................. 102
PIO Mode [Auto] ................................................................................................. 102
DMA Mode [Auto]................................................................................................ 103
S.M.A.R.T [Auto] ................................................................................................. 103
32Bit Data Transfer [Enabled] ........................................................................... 103
Floppy A [1.44 MB 3½”]...................................................................................... 104
Serial Port1 Address [3F8/IRQ4] ....................................................................... 105
Serial Port1 Mode [Normal]................................................................................ 105
Serial Port2 Address [2F8/IRQ3] ....................................................................... 106
Serial Port2 Mode [Normal]................................................................................ 106
Parallel Port Address [378]................................................................................ 106
Parallel Port Mode [Normal]............................................................................... 107
Parallel Port IRQ [IRQ7]...................................................................................... 107
Serial Port3 Address [3E8]................................................................................. 108
Serial Port3 IRQ [11]........................................................................................... 108
Serial Port4 Address [2E8]................................................................................. 108
Serial Port4 IRQ [10]........................................................................................... 108
Serial Port5 Address [2F0]................................................................................. 109
Serial Port5 IRQ [11]........................................................................................... 109
Serial Port6 Address [2E0]................................................................................. 109
