IMB-9454G Motherboard
To mount the motherboard into a chassis please refer to the chassis user guide that came
with the product.
4.8 Rear Panel Connectors
4.8.1 LCD Panel Connection
The conventional CRT monitor connector is a 15-pin, female D-SUB connector. Pin
assignments can be seen in that can be connected to external monitors.
4.8.2 Ethernet Connection
The rear panel RJ-45 connectors can be connected to an external LAN and communicate
with data transfer rates up to 1Gb/s.
4.8.3 USB Connection
The rear panel USB connectors provide easier and quicker access to external USB
devices. The rear panel USB connector is a standard connector and can easily be
connected to other USB devices.
4.8.4 Serial Connection
The rear panel serial connector (COM1) provides easy and quick access to external serial
devices
4.8.5 Keyboard and Mouse Connection
A PS/2 keyboard and a PS/2 mouse can be connected to the appropriate PS/2 connector
on the rear panel.
4.8.6 Audio Interface
AC’97 Audio signals are interfaced through the audio jack connectors. The signals include
microphone line-in, line-in stereo and speaker out stereo.
Page 90
IEI
®
Technology, Corp.
