6. Any power tools and hardware needed to set anchors or pierce the flooring
7. A multimeter capable of measuring resistance, current and voltage to 240 volts AC
8. Information relevant to the access control including wiring diagrams and legends
9. Any preferred method to punch holes in the baseplates for conduits
10. Approved sealant material to prevent fire propagation at all conduit penetration points (holes
punched in the baseplate).
1.3 Required Cables or Conduits
When you are ready to begin, check to make certain that the following cables or conduits are installed and
are protruding from the floor into the area where the PNG will be installed:
1. Power – 120 volts AC 60 Hz on individual circuit breaker of at least 15 amps – Masters only
2. Control cables for access control reader and door output (to open the portal)
3. Control cables for remote control panels (if any – available as an accessory) – Masters only
4. High voltage cross connection – between each master and slave
5. Low voltage cross connection – between each master and slave
6. Emergency release cables (if any) other than fire alarm activation – See note following
The PNG feed requires individual neutral & ground wires to be run from the distribution panel to PNG.
Fire alarm codes usually require specific wire type and gauge, and a specific type of conduit for connected
equipment. These codes also usually require a direct mechanical means to release any door. While this is
typically accomplished by dropping incoming power through a mechanical relay to the PNG, it is strongly
recommended that you consult with your AHJ for their specific requirements.
EMERGENCY RELEASE (OPENING) OF PNG
Your PNG have been designed with two different means for
opening in case of emergency. Each is different in activation
and purpose. Make certain that all Authorities Having
Jurisdiction (AHJs) approve the method you select for any fire
alarm or other emergency opening of the PNG. Refer to the
section on Emergency Opening, within this manual
