iFIT WEIDER PRO 8500 - Page 30

30
61
129
129
128
128
128
128
128
127
115
110
109
61. Insert the Long Pad Tube (115) through the Front
Leg (109). Slide a Foam Pad (128) onto each
end of the Long Pad Tube.
Attach the two Short Pad Tubes (129) to the
Leg Lever (110) in the same way.
Press a 19mm Round Cap (127) into the end of
each Pad Tube (115, 129).
62. Attach the Curl Pin (142) to the Leg Lever (110)
with an M4 x 19mm Screw (82).
82
142
110
62
60. Insert the Seat Pin (123) into the Seat Frame
(122) and the Bench Frame (107).
See step 54 Tighten the M8 Locknuts (78).
See step 55. Tighten the M6 x 40mm
Screws (39).
123
60
107
122
