IFM AL1350 - Set-up

IO-Link Master with IoT Interface DataLine 4 Ports IP 65 / IP 66 / IP 67
22
8 Set-up
Content
Read device and diagnostic information ................................................................................................23
52239
When the supply voltage is switched on, the AL1350 starts with the factory settings. The display
elements signal the current operating mode (→ Operating and display elements (→ S. 19)).
To enable parameter setting of the AL1350 via the IoT core network, the IoT interface must be
configured according to the network environment.
► Connect AL1350 via the ports X21/X22 to the IoT core network.
► Configure the IoT interface (→ IoT: Configure IP settings (→ S. 27)).
> IoT interface has valid IP settings.
> User can set the parameters of the AL1350.
Further steps:
 Set the parameters of the AL1350 (→ Configuration (→ S. 24)).
