9.1.8 IO-Link ports: Configuration of fail-safe values
52242
The user can set the fail-safe values of the outputs of the IO-Link ports X01...X04. The fail-safe values
will be activated in case of an interruption of the IoT core connection.
To configure the fail-safe values:
► Select [Port x] menu (x = 1...4).
> The menu page shows the current settings.
► Set the following parameters as required:
Name
Description
Possible values
[Fail-safe digital out]*
Fail-safe value of the output for operating mode
"digital output (DO)"
[Reset]
OFF
[Old]
Old value
[Set]
ON
[Fail-safe IO-Link]*
Fail-safe value of the output for operating mode
"IO-Link"
[Off]
No fail-safe
[Reset]
Fail-safe: OFF
[Old]
Fail-safe: old value
[Pattern]
Fail-safe: byte sequence
* ... parameter can only be changed if the IoT core controller is disconnected
► Save changed values on the device.
>
9.1.9 Info: Show device information
34065
To read the general information of the ifm IO-Link master:
► Select [Info] menu.
> The menu page shows the current settings.
Name
Description
Possible values
[Product code]
Article number of the IO-Link master
AL1350
[Device family]
Device family of the IO-Link master
IO-Link master
[Vendor]
Vendor
ifm electronic gmbh
[SW-Revision]
Firmware of the IO-Link master
[HW revision]
Hardware version of the IO-Link master
[Bootloader revision]
Bootloader version of the IO-Link master
[Serial number]
Serial number
