CR3133 CANwireless
12
Function Index Subindex Description
Activate / deactivate CAN-
open objects
0x20F4 0x00 This parameter defines whether the CANopen stack is activat-
ed or not:
0: CANopen remains active during connection (default)
1: The CANopen stack is disabled during connection.
If the CANopen stack is disabled during a radio connection, the device CANNOT be configured.
These messages are not sent if the CANopen stack is disabled:
Type Index
Tx SDO 1 0x580 + node ID
Rx SDO 1 0x600 + node ID
Heartbeat / Bootup 0x700 + node ID
NMT 0x000
8.3.2 Factory reset
The following reset variants can be triggered via the CAN interface:
Function Index Subindex Description
Reset device to factory set-
tings
0x1011 0x01 The factory configuration is restored. All recorded data is de-
leted.
Reset communication param-
eters to factory settings
0x1011 0x02 The following parameters are reset to factory settings:
- Node ID CAN1: 33
- Node ID CAN2: 34
- Baud rate CAN1: 3 (250 kbit/s)
- Baud rate CAN2: 3 (250 kbit/s)
- Heartbeat CAN1: 0 (no heartbeat)
- Heartbeat CAN2: 0 (no heartbeat)
- NMT startup CAN1: 0 (automatically set to operational)
Reset parameters defined by
the manufacturer to factory
settings
0x1011 0x19 The following parameters are reset to factory settings:
- CAN1 filter settings
- CAN1 mask settings
- CAN1 downsampling time
To carry out the factory reset via the CAN interface, CANopen software (e.g. maintenance tool) and a
communication gateway (e.g. CANfox, part no. EC2112) are required. The CANopen software writes
the value 0x64616F6C into the CANopen object index 0x1011, subindex 0x01, to perform a complete
reset.
The following example shows the factory reset via the subindex 0x01 (restoration of the default
configuration):
u Connect the device with a PC Connecting the device (Ò/11).
u Start the CANopen software.
u Write the value 0x64616F6C into the object index 0x1011, subindex 0x01 via the CANopen
software.
u Write the value to the object directory of the device.
w The ON and STATUS LEDs both light orange.
w The device is reset to factory settings.
u Wait until the STATUS LED flashes green.
w The STATUS LED flashes green.
w The device is reset to factory settings.
