CR3133 CANwireless
18
Object Index Subindex Data type Configuration
Bluetooth SPP MAC 0x3010 0x1a Visible_string Enter master MAC address
Tab.5: Bluetooth client
8.3.8 CAN - Mobile device / PC interface P2P Bluetooth
In this mode, a wireless connection is established between a CANwireless device and any other
Bluetooth device via Bluetooth. The CANwireless device needs to be configured as follows:
Object Index Subindex Data type Configuration
WLAN Enable 0x3008 0x02 Unsigned 8 0: switch off
Bluetooth Enable 0x3008 0x03 Unsigned 8 1: switch on
Bluetooth Devicename 0x3002 0x05 Visible_string Enter a unique name
Bluetooth Discoverable 0x3002 0x01 Unsigned 8 1: switch on
Bluetooth Pairable 0x3002 0x02 Unsigned 8 1: switch on
Security mode Blue-
tooth 2.1
0x3002 0x03 Unsigned 8 0: switch off
Bluetooth PIN 0x3002 0x06 Unsigned 8 Enter four-digit PIN
Default: 0000
Connection Command
1
0x3010 0x01 Unsigned 8 0: default
Server Enable 0x3010 0x15 Unsigned 8 2: turn on server
Server Type 0x3010 0x16 Unsigned 8 2: SPP (default)
8.3.9 CAN - CAN bridge via WLAN Mini Access Point (MiniAP) mode
In this mode, a wireless connection (CAN bridge) is established between two CANwireless devices via
WLAN. The devices need to be configured as follows:
Object Index Subindex Data type Configuration
WLAN Enable 0x3008 0x02 Unsigned 8 1: switch on
Bluetooth Enable 0x3008 0x03 Unsigned 8 0: switch off
WLAN Operating Mode 0x3000 0x01 Unsigned 8 2: Mini Access Point (default)
SSID 0x3000 0x02 Visible_string Enter a unique name for the WLAN
network
Authentication Type 0x3000 0x04 Unsigned 8 7: WPA/WPA2 Mixed
Authentication Key 0x3000 0x05 Visible_String Enter a secure authentication key with
at least 8 characters
DHCP 0x3000 0x09 Unsigned 8 2: server (default)
(only for WLAN MiniAP)
Hostname 0x3005 0x01 Visible_string Enter a unique device name
IP address 0x3000 0x0a Visible_string 192.168.0.34
Network mask 0x3000 0x0b Visible_string 255.255.255.0
Gateway address 0x3000 0x0c Visible_string 192.168.0.1
Primary DNS Server 0x3000 0x0d Visible_string 192.168.0.1
Secondary DNS Server 0x3000 0x0e Visible_string 192.168.0.2
Connection Command
1
0x3010 0x01 Unsigned 8 0: default
Server Enable 0x3010 0x15 Unsigned 8 2: turn on server
Server Type 0x3010 0x16 Unsigned 8 1: socket (TCP/UDP)
