3. MAIN PARAMETERS
3.1 Technical parameters table:
MODEL
MIG-200M
Input voltage (V)
1ph 230V, 50Hz
Welding mode
MIG/FLUX
MMA
TIG
Input current (A)
34
33
21
Input power(KVA)
7.5
7.2
4.7
No-load voltage(V)
60
60
60
Welding current(A)
range (A)
30~200
20~175
20~175
Welding voltage(V)
15.5~24
21~27
10.8~17
Rated duty cycle
35%
35%
35%
Welding wire dia.(mm)
0.6-1.0
N/A
N/A
Electrode dia.(mm)
N/A
1.0-4.0
N/A
Efficiency
85%
Power factor
0.7
Protection class
IP21S
Insulation class
F
* Note: The duty cycle is tested at 40°C has been determined by simulation.
* Note: The Machine with PFC version, can works under the input voltage from 85V to 260V.
While the input voltage is lower than 145V, it will switch to low voltage working mode
automatically, and the output power will be limited. Please restart the machine to recover
to the full output power, after input voltage gets to be higher than 145V.
3.2 Power supply:
MODEL
MIG-200M
Input voltage (V)
1ph 220V, 50Hz
Min. Power
Power Grid
9.5 KVA
Generator
12 KVA
Input Protection
Fuse
32 A
MCB
32 A
